ST99 LED motion sensor light and led lighting Lamp

Product Overview

Description

Welcome to use our ST99 Infrared LED Sensor Lamp!



The product is an energy-saving automatic sensor lamp, adopting integrated circuit and precise detecting components. It gathers automatism, convenience, safety, saving-energy and practical functions. Its performance is stable. It can identify day and night. The lamp can turn on when one enters detection field and can turn off automatically when one leaves detection field.





Specifications:

Power Source: 110-240V/AC                       Detection Range: 360°



Power Frequency: 50/60Hz                          Detection Distance: max.10m(<24℃)



Ambient Light:<3-2000LUX(adjustable)       Working Temperature: -20~+40℃



Time Delay:Min.10sec±3sec                       Working Humidity: <93%RH



                  Max.5min±1min                        Installation Height: 1.8-2.5m



Rated Load: 20W (AC/2050LM)                 Detection Motion Speed: 0.6-1.5m/s





Lifetime and warranty:

Lifetime (hr)	26000-45000 at least
Warranty	3 years



FUNCTIONS:

Ø Can identify day and night: The consumer can adjust working state in different ambient light. It can work in the daytime and at night when it is adjusted on the “sun” position (max). It can work in the ambient light less than 3LUX when it is adjusted on the “moon” position (min). As for the adjustment pattern, please refer to the testing pattern.

Ø Time-Delay is added continually: When it receives the second induction signals within the first induction, it will restart to time from the moment.

   Ø Adjustable Time Delay: the length of time delay could be set according to the customers’ requirement, the minimum time of this item is 10sec±3sec, and the maximum is 5min±1min.
