Gypsum powder and plasterboard making machines
US $50000-$10000000
low investment gypsum powder/stucco making machine
- Category: Gypsum Powder Machines >>>
- Supplier: Shandong Tengfei Mechanical And Electrical Technology Co. Ltd. [Shandong China]Shandong
Share on (60586990946):
Product Overview
Description
low investment gypsum powder/stucco making machine
Gypsum plaster making plant adopts boiling furnace, high-voltage electrostatic dust removing and other advanced equipment.
Gypsum plaster making plant capacity list :
Capacity/T | / Ton/hour | / Raw gypsumrock consumption T/year |
Heat supplying way |
Boiling furnace size |
30,000 | 4.2 | 36,000 |
| 4.5M×1.2M×1.4M |
50,000 | 6.9 | 60,000 | 4.5M×1.4M×1.6M | |
60,000 | 8.3 | 72,000 | 4.5M×1.6M×1.8M | |
80,000 | 11.11 | 96,000 | 4.5M×1.8M×2.0M | |
100,000 | 13.88 | 120,000 | 4.5 M×2.0 M×2.2 M | |
150,000 | 20.83 | 180,000 | 4.5 M×2.2 M×2.4 M | |
200,000 | 27.77 | 240,000 | 4.5 M×2.4 M×2.6 M | |
300,000 | 41.66 | 360,000 | 4.5 M×2.6 M×2.8 M |
Brief Introduction
Natural gypsum generally includes dehydrate gypsum and anhydrous gypsum. In order to get the valuable materials, generally, we get semi-hydrated gypsum through heating the dehydrate gypsum.
Main Technology
gypsum mine ->first breaking ->second breaking ->grinding ->calcining ->aging ->finished products (CaSO4.1/2H2O)
Raw Materials
Content of CaSO4.2H2O in gypsum mine 80%
Features of gypsum powder calcination production line
1. The calcination system is the key procedure of the production line. The vertical calciner is used in this system.
2. The main body of the calciner is composed of delicate and intensive radiation pipes. Hot air is made inside the furnace by burning oil, natural gas, LPG or coal, and it circulates between the hot air furnace and the calciner.
3. At the bottom of the calciner, the machine is mounted a roots blower, which blows the gypsum upwards through the space between the hot air pipes.
4. The gypsum powder inside the calciner is in a boiling state, so the calciner is also called boiling furnace. Being heated, the gypsum powder becomes lighter and it goes out of the calciner automatically.
Typical process of Gypsum plaster making plant
