Marine Type Thermal Oil Boilers & Steam Generator

Product Overview

Description

Marine Type Thermal Oil Boilers & Steam Generator

1. Steam generator:



1) Functions:



The control works with the steam generator to maintain a perfect level of steam and temperature in the room, while using the least amount of energy, reaching a result of soft and comfortable environment.



4 .5- 18kW power options, in-shower thermostatic control, stainless steel tank, long-life elements, automatic water feed, dual low-water protection, pressure release valve. Temperature control unit available.



2) Parameters:





Model	Power(kw)	Voltage(V)	Size(mm)	Applicable space (m3 )
HA-45	4.5	220/380	210*650*430	5
HA-60	6.0	220/380	210*650*430	6
HA-80	8.0	220/380	210*650*430	8
HA-90	9.0	220/380	210*650*430	9
HA-120	12	380	260*650*600	12
HA-150	15	380	260*650*600	15
HA-180	18	380	260*650*600	18







2. How to choose a suitable steam generator:







1. Calculate the room's volume(Length*Width*Height) in meter.
2. The power of the steam generator is equal to the CBM of the room, (eg: a 8m³ room should use a 8kw steam generator)
3. Usually, the machine power should be high than the volume number if the volume is not an integer,  so that the room can reach the temperature in short time and it's good for the machine having a longer life span.
