This series impact crusher was developed by absorbing domestic and overseas advanced technology and combining industrial and mining conditions of sandstone, it is the newest kind of impact crusher. It has the latest manufacturing technology, unique physical design. The impact crusher can crush all kinds of coarse, medium and fine materials such as granite, limestone and concrete and so on, the size of which must be less than 500mm and the compressive strength must below 350MPa, the final product of impact crusher is perfect cube without tension and crevice.

Technical Parameters of Impact Crusher
| Model | Specifications(mm) | Feed Opening(mm) | Max.Feeding Side Length(mm) | Capacyty(t/h) | Power(kw) | Total Weight(t) | Dimensions(L×W×H)(mm) |
| PF-1007 | φ1000×700 | 400×730 | 300 | 30-70 | 37-45 | 12 | 2330×1660×2300 |
| PF-1010 | φ1000×1050 | 400×1080 | 350 | 50-90 | 45-66 | 15 | 2370×1700×2390 |
| PF-1210 | φ1250×1050 | 400×1080 | 350 | 70-130 | 110 | 17.7 | 2680×2160×2800 |
| PF-1214 | φ1250×1400 | 400×1430 | 350 | 100-180 | 132 | 22.4 | 2650×2460×2800 |
| PF-1315 | φ1320×1500 | 860×1520 | 500 | 130-250 | 200 | 27 | 3180×2720×2620 |
| PF-1320 | φ1300×2000 | 993×2000 | 500 | 165-320 | 250 | 34 | 3220×3100×2620 |
| PF-1520 | φ1500×2000 | 830×2040 | 700 | 300-550 | 315-400 | 50.6 | 3959×3654×3330 |
| PF-1820 | φ1800×2000 | 1260×2040 | 800 | 600-800 | 630-710 | 83.21 | 4400×3866×4009 |

Application:

Advantage of Impact Crusher:

Our impact crushers are made of high quality raw materials, which made them durable and very easy to maintain. All impact crushers manufactured by Zhongde have quality assurance.


When packing and delivering impact crushers, the impact crusher will be packed in the export standard container, the main motor and spare parts will be put in the water-proof and sealed wooden case, we gurantee that each impact crusher will be delivered to the destination safety without any abnormal conditions.


Luoyang Zhongde Heavy Industries Co., Ltd
Luoyang Zhongde Heavy Industries Co.,Ltd. was found in 1959, formerly known as Luoyang Mining Machinery Cement Factory,has made great contribution to China’s economic development over the 50s years. It took the lead to restructuring to joint-stock enterprise in 1995, which led itself to get rapid growth, it began to settle in the modern industrial plant in Luoxin Industrial Area from the former factory in 2006.
Zhongde is China’s mining machine export base, covering an area of 98,000 square meters, with 62,000 square meters of modern heavy industrial plant and 2,800 well-trained staffs.




Luoyang Zhongde is the top 10 professional mining machine manufacturer in China, we have three factories in Henan Province, welcome to visit out factories and see the equipements personally. You can call me directly (whatsapp +86-156-3798-0311) or contact me at the followings:
