Food grade 120 kw water chiller
Food grade 120 kw water chiller
Food grade 120 kw water chiller
Food grade 120 kw water chiller
Food grade 120 kw water chiller
Food grade 120 kw water chiller
Food grade 120 kw water chiller

Food grade 120 kw water chiller

Share on (60589815709):


Price:$12,500.00

Quantity:


Product Overview

Description



Product Description



Food grade 120 kw water chiller with CE certificate




120 kw water chiller
120 kw water chiller
120 kw water chiller120 kw water chiller



Compact design,food standard,reliable quality

Product Detail





































































Chiller CompressorCopeland scroll
Chiller Air Flow528000 m3/h
Chiller Control TypeExpansion Valve
Chiller RefrigerantR22 / R134a / R407c
Chiller In/out Pipe SizeDN80
Chiller Tank610 L
Chiller Water Flow23.30 m^3
Pump Power3.75kw
Chiller Materail304# food standard
Compressor Power9.4kw*4
Product Keywords120 kw water chiller

Features:



1.Cooling temperature range 5-35 centigrade temperature.
2. High-capacity tube-in-shell evaporator with very good heat exchange performance especially under high ambient temperature condition. The heat exchange power is: 15KW
3.Tube-fin double condensers with excellent heat transfer and rapid cooling. The efficiency of condensers is 17.5KW
4. Stainless steel warm-keeping water tank,pipe,plate heat exchanger and pump
5. Overload protection for compressor, pump and blower.
6. Warm-keeping design for all piping to avoid partial convection.
7. Independent temperature controller, anti-freeze protection.
8. Phase sequence protection for control circuit, refrigeration loop controlled by high and low pressure switch.
9. R22 refrigerant to be used for efficient cooling.
















Packaging & Shipping




PACKAGE:


plywooden case.


DELIVERY TIME:


25-35 days after receiving the deposit.



120 kw water chiller





Certifications


120 kw water chiller




FAQ


120 kw water chiller



How does a chiller system work?


Chiller has two circulation,one is process water circulation,the other is refrigerant gas circulation.Heat picked up from the process.Heat transfers to refrigerant circulation.Heat is remove to air or water.






How to calculate cooling capacity for chillers?


Cooling Capacity(kw)= Flow Rate(m3/h)*Temp Change(T1-t2)/0.86

Heat Load= C(specific heat)* M(quality output per hour )*Temp Change(T1-T2)






Types of chiller system?


Air Cooled Chiller and Water Cooled Chiller.Water cooled chiller needs a separated cooling tower and has a higher efficiency,but less easier than air cooled.






Cooling capacity unit conversion?


1 kcal/h = 1.163W,1 W = 0.8598 kcal/h;
1 Btu/h = 0.2931W,1 W = 3.412 Btu/h;
1 USRT = 3.517 kW,1 kW = 0.28434 USRT;
1 kcal/h = 3.968 Btu/h,1 Btu/h = 0.252 kcal/h;
1 USRT = 3024 kcal/h,10000 kcal/h = 3.3069 USRT;






The chiller can heat?


Yes,by the electrical heating wire.Please kindly inform us the hot water temp or heating capacity.






Chiller maintenance?


Step 1: Keep Tubes Clean
Step 2: Ensure a Leak-free Unit
Step 3: Sustain Proper Water Treatment(prevent scale, corrosion)
Step 4: Analyze Oil and Refrigerant
