Product Overview

Description


Product Description

Automatic Coil Nail Collator

This collator is a special kind of automatic welding equipment for making wire coil nails. With more than 15 years experience in manufacturing this collator, we have upgraded the collator to the 4th generation with the latest technology in automatic control system. It can weld the coil nails from 20mm to 150mm with diameter ranges from 2.0mm to 4.1mm. The welding speed can be up to 3000 pcs/min. It can make various kinds of coil nails, including bright finish, coated finish, zinc plated, hot dip galvanized and stainless steel and etc..

\t
SPECIFICATIONS FOR JDJ-B COIL NAIL COLLATOR
\t
Item

\t
Specification
\t
Item
\t
Specification
\t
Welder
\t
Coil Nail Collator
\t
Wrok Power
\t
3PH, AC360V-450V, 50-60HZ, 5KW
\t
Nails Dia.
\t
2.0-3.8mm
\t
Nail Length
\t
25-130mm
\t
Vibrating Bowl
\t
3000 pcs/min d 2.5 x 50mm below
\t
Welder Power
\t
DC300V-350V
\t
Air Pressure
\t
No less than 4 kgs/cm2
\t
Rated Power
\t
8 kw
\t
Cooling Water
\t
2 Liters/min
\t
Power Max
\t
10 kw
\t
Working Area

\t
L 4m X W 3m
\t
Working Cycle
\t
7%
\t
Total Weight
\t
1600 kgs
\t
Welding Current
\t
1500A-2000A (secondary side)

2018 New Type High Frequency Welder, High speed and well welding without failure.

Dies for Coil Nail Collator

Copper Seat with High speed

High Quality Stainless Plate Vibrator

Cutting Device

2018 New Design Electric System, Simple and for easy maintance.

Main Features

1) High speed and easy for operation

2) Touch Screen Display

3) Automatic welding System

4) Low noise with high efficiency

Packing & Delivery
\t
Packaging
\t
Size
\t
2.9 X 1 X1.4M
\t



Packaging Details
\t
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
\t
Packaging
\t
Size
\t
2.1 X 1.1 X 1.45M
\t



Packaging Details
\t
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Detailed Images

Machine Parts

Name: Dies

Material: Stainless Steel

The dies are used to make different diameters of coil nails.

They can fit for smooth shank, screw shank or ring shank nails.

Machine Parts

Name: Vibrator
Steady vibrator with hard steel brackets to support.

Automatic Nail Making Machine
