200Hz 200m laser distance sensor module

Product Overview

Description

600Hz 200m laser ranging module parameters



1, the laser wavelength: 905nm

2, range: 1 ~ 200 meters;

3, control: power on self work / key control / control line control;

4, the repetition frequency: 200Hz;

5, data output: SPI

6, ranging accuracy :50mm-100mm

7, working voltage: +5V or +6~12V

8, size: 40*78*65 unit mm

9, waterproof grade: waterproof and dustproof (default)

Can be soaked in 0.5m water depth (need special requirements)

10, the working temperature: 20 ° C to +60 ° C (default)

40 ° C to +70 ° C (need special requirements)
