We have different size of uv coating machine and you can choose any one you want.
Also see video on youtube
https://www.youtube.com/watch?v=ccbF5GeI6Js
Spec
LMA14"
LMA18"
LMA24"
Coating width
350mm
450mm
600mm
Coating thickness
0.2-2mm
0.2-2mm
0.2-2mm
Cost
0.3-5Yuan/m²
0.3-5Yuan/m²
0.3-5Yuan/m²
Working speed
7.7m/min
7.7m/min
7.7m/min
Change roller speed
6min
6min
6min
Operation
Electric
Electric
Electric
Power
2.2KW
3KW
4.4KW
Voltage
220V
220V
220V
Motor
220V 25W
220V 40W
220V 40W
UV lamp
220V 2KW
220V 2KW
2pcs 220V 2KW
Machine material
Metal
Metal
Metal
Coating roller
Rubber
Rubber
Rubber
Reflector
Alloy
Alloy
Alloy
Scraper
Stainless Blade
Stainless Blade
Stainless Blade
Fan
Copper coil
Copper coil
Copper coil
Dustproof cover
Transparent acrylic
Transparent acrylic
Transparent acrylic
G.W
96KG
118KG
150KG
N.W
75KG
98KG
128KG
Packing
Plywood Carton
Plywood Carton
Plywood Carton
Machine size
740*650*520mm
900*700*580mm
1040*665*610mm
Packing size
800*740*630mm
940*730*640mm
1110*740*640mm
Optional extra UV lamp
40$/pcs
40$/pcs
40$/pcs
Optional Extra Rubber Roller
140$/pcs
150$/pcs
160$/pcs
Optional extra steel roller
145$/pcs
155$/pcs
165$/pcs
Optional Embrossing Roller
250$/pcs
260$/pcs
270$/pcs
Optional bottom box
No
No
100$/pcs
Optional transformer
300$/pcs
300$/pcs
300$/pcs
