Shoot Brand Wood Multi Rip Saw Machine with Up & Down saw blade, SHMJ230/SHMJ226A

Share on (60594802398):


Price:

Quantity:


Product Overview

Description



Product Description
















































































































































Wood Multi Rip Saw Machine with Up & Down saw blade
Feature
Professional solution, large quantities of wood, material specifications and other wood materials multi-chip SAWN
Up and down saw shaft independent electric lift, operation, quick, simple and convenient.
Six groups of the upper and lower feed rollers take the initiative to ensure that feed feeding smoothly.
Up and down saws are responsible for 50% machining, high efficiency, energy saving and material saving.
Saw uranium setting water, jet cooling system, lifting the blade utilization.
ModelSHMJ230SHMJ226A
Maximum processing width300mm250mm
Maximum processing thickness180mm180mm
Feeding speed5-20m/min5-20m
Spindle diameter\\\\
Saw shaft diameter70mm70mm
Spindle speed\\\\
Saw shaft speed4000r/min4000r/min
Air pressure0.4MPa0.4MPa
The first lower shaft30KW/40HP22KW/30HP
The first upper shaft30KW/40HP22KW/30HP
Feeding motor4KW/5.5HP4KW/5.5HP
Feeding lift motor0.75KW/1HP0.75KW/1HP
Saw shaft lifting motor0.35KW/0.5HP*20.35KW/0.5HP*2
Saw spindle motor\\\\
Total motor power65.12KW/86HP49.12KW/65HP
The first lower shaft\\\\
The second upper shaft\\\\
Upper saw shaft185-305mm185-305mm
Lower saw shaft185-305mm185-305mm
Feeding wheel diameter140mm140mm
Dust absorption tube diameter150mm150mm
Overal dimensions2900x1410x1650mm2900x1410x1650mm




Packaging & Shipping





Packing: by Plywood Case or Plastic Film


Shipping: Qingdao Port


Deliver time: 30days after receive payment





Company Information


 SHOOT Logo-1.jpg


Yantai Shoot CNC Machine Co.,Ltd


Yantai Shoot Woodworking Machine Co.,Ltd


wechat: 0086 13906451612


whatsapp: 0086 13906451612


viber: 0086 13906451612


website: www.shootmachine.com






















Our Services





Sample Availability & Policy
We can supply a sample machine for you to test, but you need to pay all costs, including machine's cost, shipping cost and customs cost.



Guarantees/Warranties/Terms and Conditions
One year



Export/Import Processing Support
We supply high-quality machine products for our clients, we deliver machine on time according to the sales contract. If the clients have other requirements, please ask us to help you.



After Sales Service
After the clients order our machines, we supply free support for one year. If the clients have questions, we can reply in 24 hours.

Prototyping
We have the expertise for reverse engineering, rapid prototyping and tooling design etc..
We can transform your drawing into a sample in a few weeks. If you don't have a drawing, send us a sample. We can measure your sample accurately, convert the data into 3D models or 2D drawings. We will forward the drawings for your approval and prototype according to the drawings.


Machining
Our combined facilities enable us to machine products to your standards. We utilize CNC equipment to make complex and high tolerance products


Assembling
We do many types of assembling. This will allow you to purchase a finished product rather than just a component.


Quality Control
Our inspectors test the products we sell for durability, accuracy and performance. We sell only quality products that meet or exceed your standards.
Training


A.Customers can get free technical training in our factory or online. Mainly training are as follow:
1.Software operation
2.Machine operation and maintenance
3.Instruction of technical parameters, as well as their setting ranges
4.Solutions for common problems

B.Also we can dispatch our technician to customers' place if customer agrees to pay visa cost,air ticket, accommodation and USD150/day/person training fee .





FAQ





1. Where you ship?
We ship worldwide to all the major ports and then transport by train or truck to your warehouse or the trucking terminals in your area. For special orders, we ship by airfreight or by express mail service through FedEx, UPS, DHL, TNT etc.
2. What is the approximate shipping time?
Express mail service like UPS, FedEx takes less than a week. We work closely with the shipping companies for the shortest delivery time.


3. What is the payment method?
We prefer irrevocable letter of credit. Telegraphic transfer is also accepted.


4. How will we handle quality issues?
Should there be defects in materials and workmanship, we will refund you with replacements from next delivery. We are not responsible for consequential damages resulted from these defects.


5. How do you pack?
We pack in heavy duty corrugated cartons or wooden crates and then strapped to pallets or steel pallets. We fumigate the wooden packages and have them degased.


6. Do you do private labeling?
Yes. We may apply private labeling and bar coding to the products you order. We can imprint your product number, your logo onto the products and the packages.
