Product Description
20 ft 30ft 40ft LPG ISO Tank Container
Tank containers series mainly used for transportation and storage of chemical liquid products and oil products, because it can be stack up placed, so that, widely used in ware house, and other industries. Tank container is a pressure vessel mounted in a frame. Frame dimensions comply with the recommendations of the International Standards Organization (ISO). The unit is designed and constructed in accordance with strict international codes for the worldwide carriage of bulk liquids on land, rail and water.
Tank containers are made of stainless steel AISI 316. Tanks are classified according to the specifications of tank shell and fittings. It is this classification that determines what type of product may be carried.
Technical Characteristic: 1. In accordance with ISO standard, international shipping import/export standard. 2. Light weight, multiple liquid carry kinds, long service life, easy clean and maintenance. 3. The 3-5 floor height stacking storage is a great space saver in warehouse.
Tank Container: Tank: insulation tank/ non-insulation tank/ plastic tank/ pressured vessel Size: 20ft tank container/ 20ft tank container (C3 pressure vessel)/ 30ft tank container/ 40ft tank container
WHAT IS THE SPECIFICATION OF LPG TANK CONTAINER?
Product Name
Spec.(feet)
Overall dimension(mm)
Volume(cbm)
Work in mass(tons)
Actual tank dimension(mm)
Design Pressure
Material
Container Storage Tank
20
6058×2438×2591
22.57
7.435
φ2300×14×5843
1.8MPa
Q345R
20
6058×2438×2591
23.5
7.8
φ2350×14/15×5843
1.8MPa
Q345R
30
9125×2438×2591
33.5
11.33
φ2250×13/14×8860
1.8MPa
Q345R
40
12191×2438×2591
40
13.68
φ2150×13/14×11450
1.8MPa
Q345R
40
12191×2438×2591
45
14.1
φ2250×13/14×11750
1.8MPa
Q345R
Medium
liquefied petroleum gas
Material
Q345R
Design pressure
1.77 MPa
Working pressure
1.61 MPa
Test pressure
2.24 MPa
Working temperature
-19 to 50 ℃
Corrosion allowance
1 mm
Filling ratio
0.9
Nondestructive testing
100% RT and MT
Thermal annealing
Whole body
Design life
15 years
Detailed Images
For the safe usage of the LPG products, we conduct several tests for the LPG tanks such as welding line density test, thermal treatment, hydra press measurement, ray nondestructive test,.etc.
LPG PRODUCT SERIES
Filling media: LPG , liquefied petroleum gas (propane), propylene, liquid ammonia, dimethyl ether and methanol, butadiene, isobutane, epoxy ethane, methyl amine in different properties such as low pressure liquefied gas under normal temperature.
----- LPG tank truck tank capacity: 5,500L-35,000L
----- LPG tank semi trailer tank capacity: 30,000L-60,000L
----- LPG storage tank tank capacity: 5,000L-120,000L
----- LPG tank container tank capacity: 20ft~40ft / 20000-50000L
----- LPG tank skid station capacity: 10000-50000L
LPG Tanker Main Accessories
1. LPG dispenser
2. LPG pump
3. LPG liquid level gauge
4. LPG safty valve
5. LPG pressure meter
6. LPG thermometer
7. LPG liquid phase
8. LPG gas phase
9. LPG Emergeny Cut-off Valves
10. LPG tanker truck manhole
Main Products List
1. LPG Gas tank truck / trailer / semi-trailer / container / storage tank / skid station 2. Water tank truck / trailer / semi-trailer / container / storage tank 3. Chemical tank truck / trailer / semi-trailer / container / storage tank 4. Bitumen tank truck / trailer / semi-trailer / container / storage tank 5. Bulk powder tank truck / trailer / semi-trailer / container / storage tank 6. Fuel tank truck / trailer / semi-trailer / container / storage tank / skid station 7. Dump truck / trailer / semi-trailer / full trailer 8. Truck mounted crane , truck crane 9. Fire truck 10. Concrete mixer truck 11. Wrecker 12. Refrigerator truck / trailer / semi-trailer 13. Sweeper truck , vacuum sweeper truck 14. Garbage truck ( type : swing arm , sealed dump , compression , hanging barrel,docking ) 15. Sewage suction vacuum tank truck 16. Fecal suction truck 17. High pressure washing truck 18. Sewage suction vacuum tank and high pressure washing truck 19. Platform transported truck / trailer / semi-trailer 20. Van truck / trailer / semi-trailer 21. High-altitude operation truck
22. Food sales truck
23. LED truck
24. Farm tractor
25. Machinery
