Sewing thread bobbin winding machine
Product Description
TS008O sewing thread winding machine with semi-auto oiling device is suitable for winding sewing thread,polyester,nylon,embroidery thread.It is with solid frame , high quality spare parts and perfect design.
Main Features
1. One spindle has one container and each container can be filled with silicone oil once per month. It is with semi-auto recycling oiling device and filter device to prevent impurity.
2. The winding speed of each spindle is 100 to 1000 meters per minute which is adjusted according to the yarn.
3. The take-up cone is beautiful and with high quality.When it works,there is nearly no noise.
Parameter
If the bobbin length is 2.5 ~ 4 inch,one spindle with two heads. If the bobbin length is 4~7inch,one spindle with one head.
Mode | TS008O-A | TS008O-H | TS008O-Y |
Con shape | Cone type | Cylinder type | Horn type |
No of spindles | 4 | 4 | 4 |
Cone for each spindle | 1or 2 | 1or 2 | 1or 2 |
Cone angle | 0°-2°20′ | 0° | 2°20′-5°57′ |
Max. winding speed | 1000mtrs/min | ||
Max. winding-up Dia. | 115mm | ||
Measurement(M^3) | 2250(L)×1050(W)×1650(H)mm | ||
Pattern round number | 2.5~4 | ||
Machine weight | 680kg | ||
Our clients
Our machines has been sold to Bangladesh,India,UZ,Egypt,Thailand,Russia, Pakistan,
Indonesia, Malaysia,Spain, Italy,etc.Mostly in Southeast Asia,South America,Africa. Most of our clients are local large yarn dyeing factory, knitting mill,blanket manufacturer,sewing thread manufacturer,embroidery thread mill,hosiery mill,nylon mill,etc.
