Product Overview
Description
Product Description
CNC Lathe - Slant Type
MT-100
FEATURES:
- 30 degree slant bed design for easy operation and easy chip removal
- Cast iron bed with optimally designed ribs with integral stiffness provides an very strong rigidity
- Big diameter bearing provides high rigidity
- High-resolution encoder mounted on spindle to provide accurate C axis positioning
- C axis with continuous indexing
- Double supported ball screws direct-driven servo motors are used for axial movements
- Servo turret or hydraulic turret is offered for users as an alternative choice
- Large disc is equipped for easy tool set up
- Special spindle motor location design reduces machine floor space
- One-piece structure on the machine structure to provide massive rigidity
- Programmable tailstock available as an option
- Large coolant tank
- Internal coolant supply through turret disc
- High pressure pump
- PLC controlled chip conveyor
SPECIFICATIONS:
MODEL | MT-100 |
Machine type | Box way |
Machine body type | Slant |
Swing over bed | 400 mm |
Standard turning dia. | 150 mm |
Max. turning dia. | 250 mm |
Max. turning length | 175 mm |
Bar capacity | 42 mm |
X-axis stroke | 220 mm |
Z-axis stroke | 200 mm |
Spindle speed | 6000 rpm |
Spindle nose | A2-5 |
Spindle thru-hole dia. | 52 mm |
Spindle bearing inside dia. | 80 mm |
Type of turret | 8 |
Height of square tool | 20 mm |
Dia. of boring bar holder | 20 mm |
3-jaw Chuck | 6" |
Stroke of tailstock | 130 mm |
Tail sleeve dia. | 60 mm |
Taper of tailstock | MT#4 |
Tail sleeve stroke | 75 mm |
Rapid feed speed | X:20 / Z:20 m/min |
Spindle motor | 7.5 / 11 kw |
Lubricating oil motor | 0.75 kw |
Cutting oil motor | 0.25 kw |
Servo turret motor | 0.75 kw |
Electric power | 15 KVA |
Hydraulic pressure | 20 L |
Lubricating oil | 1.8 L |
Cutting oil | 40 L |
Floor space (L x W) | 1850 x 1750 mm |
Net weight | 2400 kg |
STANDARD ACCESSORIES:
3-jaw hydraulic chuck |
Hydraulic system |
Hydraulic tailstock |
Live center |
Coolant system |
Morse taper sleeve |
Auto lubrication system |
Working light |
Heat exchanger for electrical cabinet |
Soft jaw |
Foot switch for chuck clamp |
MPG hand wheel |
Operation & maintenance manuals |
Tools and box |
Leveling bolts and screws |
OD tool holder |
Facing tool holder |
Boring bar holder & sleeves |
Drill sleeves |
FANUC controller |
OPTIONAL ACCESSORIES:
Bar feeder |
Parts catcher |
Tool setter |
C-axis |
VDI turret |
VDI tool holders |
Auto door |
Chip conveyor |
Chip bucket |
Transformer |
CE mark |
Safety torque limit clutch |
Hoisting hook package |
Leveling kit |
Bar feeder interface (LNS system) |
Additional tool holders and sleeves |
SIEMENS controller |
*If you have any further discussion or information, please feel free to contact us directly. Thank you.
