Polyurethane sandwich panels, cold room insulation panels
- Category: >>>
- Supplier: Changzhou Aoda Refrigeration Equipment Co. Ltd.
Share on (60603222145):
Product Overview
Description
Product Description
Specification
Type | Polyurethane sandwich cold room panel |
Core material | Polyurethane |
Steel Thickness | 0.326mm~0.8mm |
Length | 1~12m |
Fire Rating | B |
Fire Rating | 42KG/M |
Water Absorption(kg/m) | <0.30 |
Color | Any Ral Color |
Surface Appearance | Small wave, Flat, Embossment, Big rib, etc. |
Advantages | Fireproof/Insulation/Waterproof/Easy Install/Lightweight |
Usage | Cold room,prefab houses, warehouse, factory, shop, office ,etc |
Packing & Delivery
Packing Details :
Carton package Standard pacakge for monoblock unit is carton, it is with pallet on the bottom for easy transportation. Sutiable
for container shipment.
Plywood package
For LCL delivery without container, you can update the package with plywood, the unit can be well protected.
Plastic film for panel
Each panel is well wrapped with plastic film respectively, the corner is protected with brown paper.
Delivery Details : 15 days
Carton package Standard pacakge for monoblock unit is carton, it is with pallet on the bottom for easy transportation. Sutiable
for container shipment.
Plywood package
For LCL delivery without container, you can update the package with plywood, the unit can be well protected.
Plastic film for panel
Each panel is well wrapped with plastic film respectively, the corner is protected with brown paper.
Delivery Details : 15 days
Company Profile
Changzhou AODA is specialized in making cold storage room, cold room panel and cold room door. Aoda cold storage is widely used in food, supermarkets, hotels, aquatic products, pharmaceutical, biological, chemical, industrial and mining enterprises and other industries. It can be customized according to the requirements and library features. The constant pursuit of excellence, has the ability to meet the special requirements of customers to win the satisfaction. In the past two years, the brand awareness has improved rapidly, the products are exported to spread all over the country, and best-selling overseas.
FAQ
Q1. What is the material of cold storage panel?
Stainless steel, Painted galvanized steel or Galvanized steel
Q2. What is the thickness of the cold storage panel?
The thickness of the cold storage panel is 75mm, 100mm, 150mm, 180mm, and 200mm.
Q3. What is the applicable temp range base on different thickness?
1.75mm medium temperature (-5°C or above)
2.100mm low temperature (-15°C or above)
3.150mm ultra low temperature (-35°C or above)
4.200mm ultra low temperature (-50°C or above)
Q4.If you want to customize the cold storage, the details about the cold storage as follows you should tell me.
1. What is the size of the cold storage?
2. What is the cold storage used for?
3. What is the required temperature of the cold storage?
Q5.What's the difference of plug-in PU sandwich panel compared with cam-lock PU sandwich panel?
Plug-in PU sandwich panel is fixed by self tapping screw.(Mainly used in large duty cold storage)
Cam-lock PU sandwich panel is fixed by cam lock. (Mainly used in small duty cold storage)
Q6.How is the temperature displayed on a cold room / freezer?
All controllers on cold rooms have an electronic display that will show the set point and running temperature.
Q7.Packaging & Shipping
Packing: Pallet, wooden case or with outer carton, or as per customers' specific requirements.
Shipping: Sample By Express (DHL /UPS /TNT /FedEx /EMS), By Air, Mass products By Sea.
Q8.How can you guarantee the quality?
A: 2 year's warranty against B/L date. If quality problem occurs, we promise to replace goods or return your payment accordingly.
Q9.How many years of no rust for your PU sandwich panel?
10 years.
Q11.What is your MOQ?
ur MOQ is usually 5 set. Panel usually 250 ㎡
Q12.What is your delivery time?
Pu sandwich panel ≤500 m2 7 working days delivery,Pu sandwich panel ≥500 m2 15~25 working days delivery.
Stainless steel, Painted galvanized steel or Galvanized steel
Q2. What is the thickness of the cold storage panel?
The thickness of the cold storage panel is 75mm, 100mm, 150mm, 180mm, and 200mm.
Q3. What is the applicable temp range base on different thickness?
1.75mm medium temperature (-5°C or above)
2.100mm low temperature (-15°C or above)
3.150mm ultra low temperature (-35°C or above)
4.200mm ultra low temperature (-50°C or above)
Q4.If you want to customize the cold storage, the details about the cold storage as follows you should tell me.
1. What is the size of the cold storage?
2. What is the cold storage used for?
3. What is the required temperature of the cold storage?
Q5.What's the difference of plug-in PU sandwich panel compared with cam-lock PU sandwich panel?
Plug-in PU sandwich panel is fixed by self tapping screw.(Mainly used in large duty cold storage)
Cam-lock PU sandwich panel is fixed by cam lock. (Mainly used in small duty cold storage)
Q6.How is the temperature displayed on a cold room / freezer?
All controllers on cold rooms have an electronic display that will show the set point and running temperature.
Q7.Packaging & Shipping
Packing: Pallet, wooden case or with outer carton, or as per customers' specific requirements.
Shipping: Sample By Express (DHL /UPS /TNT /FedEx /EMS), By Air, Mass products By Sea.
Q8.How can you guarantee the quality?
A: 2 year's warranty against B/L date. If quality problem occurs, we promise to replace goods or return your payment accordingly.
Q9.How many years of no rust for your PU sandwich panel?
10 years.
Q11.What is your MOQ?
ur MOQ is usually 5 set. Panel usually 250 ㎡
Q12.What is your delivery time?
Pu sandwich panel ≤500 m2 7 working days delivery,Pu sandwich panel ≥500 m2 15~25 working days delivery.
