4210HA Fireproof Insulation Thermal Paper Roll Ceramic Fiber Paper
4210HA Fireproof Insulation Thermal Paper Roll Ceramic Fiber Paper
4210HA Fireproof Insulation Thermal Paper Roll Ceramic Fiber Paper
4210HA Fireproof Insulation Thermal Paper Roll Ceramic Fiber Paper
4210HA Fireproof Insulation Thermal Paper Roll Ceramic Fiber Paper

4210HA Fireproof Insulation Thermal Paper Roll Ceramic Fiber Paper

Share on (60605345136):


Price:

Quantity:


Product Overview

Description


Product Description



Technology Data:

\t
Grade
\t
Standard
\t
High Pure
\t
High Aluminium
\t
Zirconium
\t
ORICTION Style
\t
4210ST
\t
4210HP
\t
4210HA
\t
4210HZ
\t
Glassification Temperature (°C)
\t
1050
\t
1260
\t
1350
\t
1430
\t
Max Working Temperature

(°C)
\t
800
\t
1050
\t
1200
\t
1400
\t
Shrinkage on Heating (%)
\t
800°C×24h≤-3
\t
1000°C×24h≤-3
\t
1280°C×24h≤-3
\t
1400°C×24h≤-3
\t
Organic Content (%)
\t
≤5
\t
≤5
\t
≤5
\t
≤5
\t
Thermal conductivity by mean temp. (W/m.k.) (250kg/m3)
\t
200°C
\t
0.055~0.065
\t
0.060~0.070
\t
400°C
\t
0.110~0.120
\t
0.105~0.125
\t
600°C
\t
0.160~0.170
\t
0.170~0.180
\t
Chemical Composition
(%)
\t
AL2O3
\t
43
\t
47
\t
55
\t
38
\t
SiO2
\t
53
\t
51
\t
44
\t
44
\t
Fe2O3 + Ti2O3
\t
≤1.2
\t
≤0.3
\t
≤0.3
\t
≤0.2
\t
CaO + MgO
\t
≤0.3
\t
≤0.3
\t
≤0.3
\t
≤0.2
\t
NaO + KO2
\t
≤0.5
\t
≤0.3
\t
≤0.3
\t
≤0.2
\t
Density (kg/m3)
\t
200±10
\t
Size (mm)
\t
Length: 60000/40000/30000/20000/15000/12000

Width: 1220/610

Thickness: 1~6

(Other sizes and shapes on request. )
\t
Package
\t
Carton box

Ceramic Fiber Paper Description:

1. Ceramic fiber paper is manufactured from high_grade ceramic fiber with low slag ball content, and formed into excellent flexible sheet through unique beating, des-lagging, slurry-compounding, long net forming, vacuum water removal, drying, cutting and rolling processes.

2. It is featured with high temperature resistance and heat insulation and high antimelt capability, very low thermal conductivity, chemical corrosion resistance and thermal shock stability.

3. So the paper can be widely used in building, glass industry for teeming pads separation. It provides maximum heat resistance and thermal insulation in limited space.

Ceramic Fiber Paper Applications:

1. Industrial furnace, Heat treatment, High temperature pipe.
2. Insulating materials of boiler, turbine and nuclear power.
3. Insulating material for face and top of industrial furnaces and heating device.
4. Excellent sound insulation for Construction Fire protection.
5. High temperature filter material for nonferrous metal.

Ceramic Fiber Paper Advantages:

1. Low thermal conductivity heat storage and heat capacity.
2. Excellent heat insulation.
3. Excellent chemical stability.
4. Shock and chemical attack resistant.
5. Low thermal conductivity and shrinkage.
6. Resilience under working condition, low shrinkage under high temperature.
7. Excellent sound insulation and resistance of folding.
