Shredder hammer for sugar mill with interchangeable hammer tips
- Category: >>>
- Supplier: Hunan Hyster Material Technology Co. Ltd.
Share on (60609788382):
Product Overview
Description
Factory in china trade assurance shredder hammer for sugar mill with interchangeable hammer tips
Shredder/Grinder Hammer Tips are bi-metallic composites having 700 BHN hardness and available in various sizes and shapes, shredder hammer tips can be used in sugar or coal industry to do crushing and shredding performance, it has excellent impact and abrasion resistance properties & enhanced service life.
These shredder hammer tips are used as an alternative to conventional hardfacing in :
• Crusher mills
• Hammer mills
These hammers find application in
i) Sugar Industry
ii) Mining & Mineral Processing Industry.
iii) Cement & Steel Industry
HYSTER-Wear Knife Edges are sharp edge blocks that are cost-effective alternatives to conventional expensive hard facing methods. They have sharp edges that could retain their sharpness and cutting efficiency longer than conventional methods.
Product Description
Hyster offer our clients a wide range of wear products and professional wear solutions. We also welcome custom made one off's and consumables.
Following are our laminated wear blocks:
Laminated wear blocks---the most common types are:
1) Chocky bars
2) Standard wear bars
| ITEM | SIZE(MM) | LENGTH | WIDTH | WEAR THICKNESS | BASE THICKNESS | N.W.(kg) |
| DLP 919 | 200x25x25 | 200 | 25 | 15 | 10 | 1.0 |
| DLP 920 | 200x75x75 | 200 | 75 | 63 | 12 | 8.9 |
| DLP 4 | 300x38x33 | 300 | 38 | 25 | 8 | 8.9 |
| DLP 1191 | 300x25x25 | 300 | 25 | 15 | 10 | 1.5 |
| DLP 1192 | 300x150x60 | 300 | 150 | 48 | 12 | 21.1 |
| DLP 295 | 153x50x33 | 153 | 50 | 25 | 8 | 1.5 |
| DLP 2265 | 115x50x50 | 115 | 50 | 38 | 12 | 2.3 |
| DLP 1101 | 150x50x50 | 150 | 50 | 40 | 10 | 2.9 |
| DLP 369 | 210x50x50 | 210 | 50 | 38 | 12 | 4.1 |
| DLP 125 | 230x50x50 | 230 | 50 | 38 | 12 | 4.5 |
| DLP 453 | 294x50x50 | 294 | 50 | 40 | 10 | 5.8 |
| DLP 201A | 432x50x50 | 432 | 50 | 38 | 12 | 8.5 |
| DLP 202 | 459x38x31 | 459 | 38 | 25 | 6 | 4.2 |
| DLP 184 | 150x75x39 | 150 | 75 | 29 | 10 | 3.4 |
| DLP 619 | 150x75x60 | 150 | 75 | 50 | 10 | 5.3 |
| DLP 337 | 127x50x50 | 127 | 50 | 38 | 12 | 2.4 |
3) Shaped wear bars
4) Wear buttons& donuts
5) Shredder/Grinder hammer tips
| ITEM | TYPE | DIMENSION(MM) | N.W.(KG) |
| DLP 1340 | flat | 80x56x45 | 1.6 |
| DLP 1052 | flat | 80x80x45 | 2.4 |
| DLP 920 | flat | 90x50x45 | 1.6 |
| DLP 653 | flat | 90x90x45 | 2.9 |
| DLP 1654 | V type | 90x90x50 | 3.0 |
| DLP 1927 | U type | 90x90x55 | 3.1 |
6) Bi-metallic wear plates
7) Knife edges(DLP1065-22, 203X22X50MM; DLP1265-22,305X22X50MM; DLP1065A-16, 203x16x50mm, DLP1065A-25, 203x25x62mm; DLP1265A-25, 305x25x56mm)
8) Skid bars, skid blocks(DLP412, 250x150x45mm; DLP413, 200x150x45mm; DLP414, 250x250x45mm)
9) Wafer strips, WS25, WS40, WS50, WS65;
10) Elbow wear blocks
11) Other sizes and shapes
12) Multi-function gradient cutter tooth
13) Rockbox liners
14) Micro-ledges
Overlay wear plates: standard sheet size 1500x3000mm, thickness 4+4(8mm), 6+4(10mm), 6+6(12mm), 8+5(13mm), 8+6(14mm), 10+5(15mm), 10+10(20mm), 12+12(24mm), 12+17(29mm).
Please contact us if you have any interest. thank you!
Product Show
Pictures of shredder hammer for sugar mill with interchangeable hammer tips:
We are ISO9001:2008 manufacturer for:
1. Bi-metallic wear blocks/plates, Chocky bars, Wear Buttons(white iron+mild steel, 63HRC)
2. Sugar Cane Shredder hammer tips and knife edges.
3. Overlay wear plates.
4. Tungsten carbide/Ni-hard wear parts.
for Mining, Sugar, Quarrying, and other heavy industries.
Technical Datas
Wear Material: ASTM A532 15/3CrMo white iron
Base Material: carbon steel
Hardness: 63HRC / 700BHN
FAQ
Q: Are you trading company or manufacturer ?
A: We are ISO9001:2015 Certificated factory.
Q: How long is your delivery time?
A: Generally it is 5 days if the goods are in stock. or it is 15 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: 30% in advance.,balance against copy of B/L, payable via T/T.
Why Choose Hyster?
Why Our Partner Choose Hyster?
1. We have completly production line. Annual output of bi-metallic wear blocks/bars/plates is more than 3000tons, capable to produce about 1200 different sizes and shapes; annual output of wear-resistant castings is more than 3000 tons, and hardfacing wear plates more than 2000 tons.
2. We have a very skilled team of workers and engineers with more than 15 years of experience.
3. We have independent research and development capabilities.
4. We are fully equipted with all necessary testing devices.
5. Hyster has its own License for Import and Export and also a professional team of sales staff, who are familiar with English, Spanish, Russian and international logistics.
How We Work With Our Partners?
1. We always welcome OEM / Distributor / Agent / Dealer.
2. We supply continuously R&D Support.
3. We guarantee the fastest Service & Delivery.
4. We provide the most competitive Price & Top-grade Quality.
> Confidentiality > Professional > Innovation > Efficient
Quality Guarantee
Quality Guarantee
Quality Report to be submit ahead of delivery: include Metallographic Analysis & Hardness & Chemical Composition Analysis & Welding Quality(UT) & Dimensions & G65 Dry Sand/Rubber Wheel Abrasion Test. 12 month warranty on quality.
The company is certified with ISO9001:2015. We have a dedicated R&D team that can tailor various products with special requirements (such as wear resistance, corrosion resistance, impact resistance, heat resistance, etc.) and provide professional wear resistance solutions. Since its establishment, the company has carried out a lot of experiments on improving the wear resistance and composite bonding strength, various heat treatment technology on different products, and the selection of wear-resistant alloys under different working conditions. The production process and product performance are continuously optimized.
