Paper mill Pulp Pump
- Category: >>>
- Supplier: Shandong Easttai Paper Machinery Co. Ltd [Shandong China]Shandong
Share on (60610366005):
Product Overview
Description
pulp pumps
Product description
DSP Series hi-efficiency technical pulp pump
Application:
It is suitable for transporting pulp, cotton pulp and sewage water with fiber.
Design features:
1.Adopt the technology of ANDRITZ
2.Single-stage and single suction
3.Semi-opened impeller
4.It has auxiliary impeller seal and impeller clearance adjustment plate
5.High efficiency
6.save energy
Main technical data:
Flow (m³/h) | 13-2000 |
Head (m) | 6-55 |
Power (kw) | 1.1-250 |
Rotation speed (r/min) | 980-1480 |
Connection diameter (mm) | 50-350 |
Pulp concentration (%) | ≤5 |
Working pressure (mpa) | ≤1.0 |
DWP Series Single-suction low pulse pump
Application:
It is suitable for the pulp-feed system of high or middle speed, and is also good for upgrading of old paper machine.
Design features:
1.Adopt the technology of ANDRITZ
2.Single-stage and single suction
3.Combination of both semi-opened and closed impeller
4.It has auxiliary impeller seal and Impeller clearance adjustment plate
Main technical data:
Flow (m³/h) | 55-1920 |
Head (m) | 4-50 |
Power (kw) | 3-250 |
Rotation speed (r/min) | 980-1480 |
Connection diameter (mm) | Φ100-350 |
Pulp concentration (%) | ≤1.5 |
Working pressure (mpa) | ≤1.0 |
DSWB Series double-suction low pulse pump
Application:
It is suitable for the pulp-feed system of high or middle speed.
Design features:
1.Adopt the technology of ANDRITZ.
2.Big twist vanes and stagger outlet intercalation helps to decrease the flow impulsion and depressthe flow impulsion and depress the flow pulse efficiently.
3.Horizontal type, easy to install
4.Special seal,
5.Non-leakage
Main technical data:
Flow (m³/h) | 300-2600 |
Head (m) | 9-85 |
Power (kw) | 45-355 |
Rotation speed (r/min) | 980-1480 |
Connection diameter (mm) | Φ200-350 |
Pulp concentration (%) | ≤1.5 |
Working pressure (mpa) | ≤1.0 |
Our services
1. Quality guaranteed.
2. Competitive price.
3. Fast delivery time.
4. Good after sales service.
5. If anything you need help, we will reply you within 24hours.
6.Technical service with a technical service team
Company information
EASTTAI is a China based engineering company and machinery supplier committed to offer complete solutions and provide high cost-performance equipments related to stock preparation and paper-making industry. For years, we have insisted on taking customer’s value as our center and having strict quality-control and innovation in the whole process.
With advanced technology and excellent equipment, we provide one-stop service from consultation, process design and optimization, manufacture, installation, commissioning and personnel training and so on. At the same time, we can supply all kinds of stock preparation and paper making equipment and accessories. Besides, we can custom design according to customers’ requirements.
Our products have reliable quality and superior performance and have been exported to Poland, Greece, Turkey, Iran, India, Pakistan, Bangladesh, Thailand, Indonesia, Philippines, Malaysia, Vietnam, Mexico, Guatemala, Costa Rica, Columbia, Egypt etc. We have established long-term cooperation relationship with many paper mills abroad.
Honesty, cooperation and win-win are important to us. We insisted on serve our customers with high quality products, sincere service and good reputation. Thanks for the long-term trust and favor from our customers. Hope we can cooperate sincerely and make progress together with our customers both of new and old.
If you interest in our machine,please contact me.
Easttai Industrial Limited, China
Shandong Easttai Paper Machinery Co. Ltd.
Professional solutions and services for pulp & paper industries
Office Fax/Tel:+86-531-83212788 Mobile: +86-18560219729
E-mail : easttai1@easttai.net Skype/Msn: easttai11@hotmail.com
Add:The Central Mansion,Zhangqiu,Shandong,China.
