WRDZ New Solar Lightning Suppressor Electrical Surge Protective Device
WRDZ New Solar Lightning Suppressor Electrical Surge Protective Device
WRDZ New Solar Lightning Suppressor Electrical Surge Protective Device
WRDZ New Solar Lightning Suppressor Electrical Surge Protective Device
WRDZ New Solar Lightning Suppressor Electrical Surge Protective Device
WRDZ New Solar Lightning Suppressor Electrical Surge Protective Device
WRDZ New Solar Lightning Suppressor Electrical Surge Protective Device

WRDZ New Solar Lightning Suppressor Electrical Surge Protective Device

Share on (60613470808):


Price:$13.43 - $17.91

Quantity:


Product Overview

Description


































































































Rated Voltage(max. continous voltage)Uc1000V
Nominal discharge current(8/20μs)In20kA
Max. discharge current(8/20μs)Imax50kA
Max. discharge current(10/350μs)Iimp7kA
voltage protection levelUp≤4.5kV
Response timetA≤25ns(L-N)
Max.Back up fuse 125AgL/gG
Operating Temperature rangeTu-40~80℃
Cross-sectional area 1.5mm²~25mm² solid/35mm²flexible
Mounting on 35 DIN rail
Enclosure material Purple module & light gray,UL94-V0
Dimension 4mods
Type of remote signaling capacity Switching contact
Switching Capacity AC:250V/0.5A; DC:250V/0.1A; 125V/0.2A; 75V/0.5A
Cross sectional area for temote signaling contact Max.1.5mm² solid/flexible
Test standards YD/T 1235.1; GB 18802.1; IEC 61643-1
Certification CE TUV CQC RoHS
