Low price flat plate solar water heater, flat panel collector with high efficiency

Product Overview

Description

Low price flat plate solar water heater, flat panel collector with high efficiency

 2.Features and advantages

Flat Plate Solar Water Heater Features:
1.Using patent advanced coating technology with high efficiency performance.
2.High strength aluminium-alloy structure with surface varnish baking
3.High visual shape ,easy installation ,maintenance free
4.Can be combined with existing energy source

Advantage:
1.12 years sale experience
2.Certificate:CE,ISO9001-2008,SRCC,Solar keymark,SGS,CCC
3.Life span:Approximate to 15 years
4.We can customize according to customers' requirement
5.Warranty time :5 years



Advantages of no welding:

Welding is a damage to stainless steel. We wrap the cover on the main inner tank, there is no welding, so there is no leaking.



3.Specifications of Non-welding non-Pressure Flat Plate Solar Water Heater





Description	Flat plate non-pressure solar water heater
Material of inner tank	Food grade SUS 304 stainless steel, 0.4mm (Diameter:360mm)
Material of outer tank	Galvanized, 0.4mm (Diameter:460mm)
Tank insulating layer	50mm high-density polyurethane foamed
Flat-plate collector	solar collector(Black chrome,2000*1000*80mm)
Bracket	Stronger galvanized steel sheet (25°, 30°, 35°, 45°, 50°)
Fastening pieces	Stainless steel screws & nuts
Heat preservation	72 hours
Certification	passed CE/ISO9001/CCC
Capacity/L		100(1 pc)	150(1 pc)	200(2pcs)	250(2 pcs)	300(3pcs)

6.Flat panel Solar Water Heater Model for Your Reference
