| Position | Mid Motor |
| Construction | Geared Motor |
| Nominal Voltage | 24/36/48 V |
| Power | 350 W |
| RPM | 110-130 |
| Torque | 120 Nm |
| Efficiency | ≥ 78 % |
| Brake | Disc Brake, V-Brake, etc. |
| Bus System | RS232, RS 485, Lin Bus, etc. |
| Weight | 4,3 kg |
| Cadence (Pulses/Cycle) | 1 |
| Reduction Ratio | 1:21,9 |
| Magnet Poles | 16 |
| Noise | < 55 dB |
| Hall Sensor | optional |
| Connector | optional |
| IP-Code | IP 65 |
| Compliance | ROHS |
| Label | CE |

| Dimension A | 208 mm |
| Dimension B | 110mm |
| Dimension C | 68 mm |
| Dimension D | 159 mm |
| Dimension E | 88 mm |





Q: How to make the order:
A: You have 4 ways to contact us to make the order: by email, by Skype, by phone and by Trademanager. We would reply you within 6 hours.
Q: How long it takes from the order to delivery:
A: After the order confirmed and the buyer pay the deposit, we would count the delivery time. Usually the parts delivery time is less than 15 days, and the whole kits delivery time is less than 25 days. Of course, if you need the products ugently, please let us know, we would confirm the delivery time is ok or not before the order.
For more FAQ, please check FAQ
We not only sell the e bike conversion kit, also provide professional service.
We would give advice according to customer's requirements and need.
We are not only selling one part or one products, we provide whole soultion.
We provide long time warranty:
e bike frame: 3 years
motor: 3 years
battery: 1.5 year
battery charger: 1 year
controller: 1 year
other electric bike parts: 1 year
