Высококачественная катушка/полоса из бериллиевой меди C17200 C17300 Becu на заказ
- Category: Copper Strips >>>
- Supplier: Dongguan Dechuang Hardware Co. Ltd.
Share on (60618717497):
Product Overview
Description
Details Show
Real Take
Relevant Property
| Grade | Be | Co | Ni | Pb | Cu |
| 17200-HT 17200-M | 1.8-2.0 | Co+Ni<0.2 | -- | Balance | |
| 1720HMB | 1.8-2.0 | Co+Ni+Fe<0.6 | Balance | ||
| C17500-HT | 0.4-0.7 | 2.4-2.7 | -- | -- | Balance |
| C17530-HT | 0.15-0.5 | 0.35-0.6 | -- | -- | Balance |
| Grade | Temper | Heat Treatment | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation (%) | Vickers Hardness (HV) | 1ACS% | |
| C17200 | A | TB00 | -- | 410 - 540 | -- | > 35 | 90-160 | 15-19 |
| 1/4H | TD01 | -- | 510 - 620 | -- | > 10 | 121-185 | 15-19 | |
| 1/2H | TD02 | -- | 580 - 690 | -- | > 5 | 176-216 | 15-19 | |
| H | TD04 | -- | 685 - 835 | -- | > 2 | 216-287 | 15-19 | |
| AT | TF00 | 315°C 3h | 1100 -1380 | > 960 | > 3 | 353-413 | 22-28 | |
| 1/4HT | TH01 | 315°C 2.5h | 1180 -1400 | > 1030 | > 2 | 353-424 | 22-28 | |
| 1/2HT | TH02 | 315°C 2h | 1240 -1440 | > 1100 | > 2 | 373-435 | 22-28 | |
| HT | TH04 | 315°C 2h | 1270 -1480 | > 1140 | > 1 | 373-446 | 22-28 | |
| Thickness x Width | Thickness x Width | Thickness x Width | Thickness x Width |
| 0.1mm x 200mm | 0.15m m x 200mm | 0.2mm x 200mm | 0.25mm x 200mm |
| 0.3mm x 200mm | 0.4mm x 200mm | 0.5mm x 200mm | 0.6mm x 200mm |
| 0.8mm x 200mm | We Can Customize Any Size, Please Contact US. | ||
