Automatic PP Spunbonded Nonwoven Fabric Making Machine

Product Overview

Description

Automatic PP Spunbonded Nonwoven Fabric Making Machine

This production line is filament polypropylene fiber spunbonded non-woven fabric equipment. Its raw material is polypropylene(PP), take the principle of spinning man-made fibres, during polymer filature, continuous filament is extended into fiber, during which is finished by mechanical hot pressing.
The machine assembly we adopt is new advanced veneer integer slot air flow draw technology, the whole process from material feeding to cloth output is automatic control short production flow, high working efficiency. The non-woven fabric we produce has high strength, good softness, innocuity, acterium-proof, corrosion resistance, high-level draw strength and elongation rate.
They are widely used for dress, decoration materials, medical sanitation materials, daily life products and in the industrial, agricultural fields. In addition, this production line can produce non-woven fabrics of different color, differen grams, different lines according to users'demand.

Model	yf-ss1600	yf-ss2400	yf-ss3200
Width of fabric	1600 mm	2400 mm	3200 mm
Daily output	9 Tons	12 Tons	18 Tons
Max.Diameter of Product in Roll	φ 2000mm	φ 2000mm	φ 2000mm
Monofilament Fineness	S:2.0-2.5denier	S:2.0-2.5denier	S:2.0-2.5denier
GSM of Product	10-150g/m2	10-150g/m2	10-150g/m2
Mechanical Design Speed	300m/min	300m/min	300m/min
Actual Production Speed	250m/min	250m/min	250m/min
Installation power	900kw	1216kw	1371kw
Working power	280 Kw	490Kw	685 Kw
Installation dimension (L × W × H)	30 × 9 × 12 m	30 × 11 × 12m	30× 15 × 12 m
Remark: embossing rollers with point pattern, cross pattern, or line pattern can be made to order. Adjustable range of weight: 9-250gsm
