Product Overview
Description
Product Description
capacitors 40/85/21
Product Detail
| Color | Black |
| Product name | Fan Cbb61 Capacitor |
| Material | Metalized Polypropylene |
| Capacitance tolerance | 5%(J) |
| Terminal | Lead Wire |
| Package / Case | Normal Package |
| Certificate | RoHS/CE/ISO9000 |
| Product Keywords | capacitors 40/85/21,capacitors 275v x2,capacitors 25/85/21 |
Application
this capacitor is widely used as start-up and running capacitor that is special for electric appliances
such as electric fan, ventilators and exhaust fan.
General specifications:
Item | Technical Specification |
Operating Temperature | -40°C-+70°C |
Capacitance Range | 0.8uf-25uf |
Capacitance Tolerance | J (±5%), K(±10%) |
Rated Voltage | 250V, 400V, 450V, 630V |
Withstand Voltage | AC≥1.75Un 2S (Imax≤1.3InA) |
Dissipation Factor | ≤0.004 (20°C,1kHz) ≤0.002(20°C,100Hz) |
Insulation Resistance | ≥3000S |
Weather Category | 40/70/21 |
Standard dimensions:
Capacitance Range (uf) | Rated Voltage | ||
250V | 400V-450V L*W*H | 630V | |
1 | 36.5×11×24.5 | 36.5×11×24.5 | 36.5×16×29.5 |
1.5 | 36.5×11×24.5 | 36.5×11×24.5 | 36.5×16×29.5 |
2 | 36.5×11×24.5 | 36.5×16×29.5 | 38×20×30 |
2.4 | 36.5×11×24.5 | 36.5×16×29.5 | 47×17.5×34.5 |
3 | 36.5×16×29.5 | 38×20×30 | 47×17.5×34.5 |
3.5 | 36.5×16×29.5 | 38×20×30 | 47×20×37.5 |
4 | 38×20×30 | 47×17.5×34.5 | 47×20×37.5 |
5 | 47×17.5×34.5 | 47×20×37.5 | 50×23×40 |
6 | 47×17.5×34.5 | 47×20×37.5 | 50×23×40 |
8 | 47×20×37.5 | 50×23×40 | 58×25×42 |
10 | 47×20×37.5 | 58×25×42 | 58×25×42 |
12 | 47×20×37.5 | 58×25×42 | 58×31×57 |
15 | 50×23×40 | 58×28×50 | 58×31×57 |
20 | 58×25×42 | 58×31×57 |
|
25 | 58×25×42 |
|
|
NOTE: General size listed in above from, special value on size is available by consulting on request. Please specify requirements of size when sampling and purchasing capacitors.
