Product Overview
Description
Product Description
High quality magnesite is the majoritary component of magnesia cupels.
As a rule of thumb, magnesia cupels have a superior quality and offer many advantages:
l Great mechanical strength, and are not affected by atmospheric conditions (not hygroscopic). .
l The prill or bead does not adhere to the fire assay cupel surface,
l When using magnesia cupels, the assay have a reduced tendency to freeze.
l No cracking or spiting, and the beads do not attach to the fire assay cupel surface.
l Magnesia cupels provide security and quickly absorb great amounts of litharge without cracking or pitting.
l Our magnesia cupels allow to reduce the Cupellation temperature and time, resulting in minimal losses, higher accuracy and better yields.
l Perfect uniformity of Quality of cupels
l Quality and performance are continuously improved
Magnesia cupels swiftly absorb 70% of their weight in litharge (PbO) at 980ºC without leaking.
Magnesia cupel data
Size | A | B | C | D | E | F |
mm | mm | mm | mm | mm | mm | |
4A | 22 | 27 | 20 | 7.5 | 24 | 6 |
4AS | 22 | 27 | 20 | 8 | 24 | 9 |
6A | 26 | 40 | 30 | 6 | 30 | 12 |
7 | 22 | 39.5 | 29 | 6.5 | 31.2 | 11 |
7A | 32 | 40 | 30 | 12 | 30 | 12 |
7AL | 28.5 | 39.7 | 30 | 6 | 31.2 | 12.3 |
7AS | 34 | 40 | 30 | 14 | 30 | 12 |
8 | 27.1 | 44.3 | 34.6 | 9 | 34.2 | 8.5 |
8A | 35 | 45 | 37 | 13 | 38 | 13 |
9A | 34 | 51 | 39 | 14 | 40 | 15 |
Packing & Shipping
Packed in carton with pallets
Service
l High level of Quality Control at each stage of production
l Packaged to your requirement
l Prompt international shipping
l Consultation available as needed.
Packaging pictures:
