Product Overview

Description



Product Description

1.Android smart cloud terminal,Intel 64 bit CPU and large capacity memory.

2.High security:providing multiple security protection,ensure the security of sensitive data.

3.Support for multitask running at the same time:Support and send implementation software in parallel,meet the application requirements of personalized business.

4.Flexible configuration:providing a variety of flexible communication mode selection,ensuring communication speed and security of transactions.

5.High speed printing:set-in high speed thermal printer,easy to load paper.

6.Long standby:7.4V 5200mAh large capacity lithium battery.










Specifications



Items

Specifications

ModelT-85T-85 LTE

CPU

4x Cortex-A7 1.3GHz  / 4x Cortex-A5 1.5GHz

4x Cortex-A53 1.5GHz  / 8x Cortex-A53 1.7GHz
GPUARM Mali-400MP2 533MHzARM Mali-T720 MP2 450MHz~600MHz

Opreating System

Android4.4.2

Android 6.0

Memorizer

4GB ROM+1GB RAM + 4GB ROM+512MB RAM

1GB/2GB/3GB ROM + 8GB/16GB/32GB eMMC
Communication GSM/GPRS ( 850 / 900 / 1800 / 1900 ) MHz ;WCDMA (850 or 900 / 1900 / 2100 )MHz ;WiFi 802.11b/g/n;Bluetooth BT 4.0;GPS;Support A-GPS.

GSM/GPRS ( 850 / 900 / 1800 / 1900 ) MHz ;

TDS(34/39 ),WCDMA(B1/B2/B5/B8 ),CDMA2000(BC0);

TDD(38/39/40/41 ),

FDD(1/2/3/4/5/7/8/17/20/12/13/28);802.11b/g/n;Support hot spots(5G 802.11.AC);BT4.0LE;

GPS,support for A-GPS;

BDS(option)

Screen

Operator Display : 1280×800 Dot matrix 10.1" TFT LCD+TP;

Customer Display : 128×32 Dot matrix STN  monochrome

Keyboard

3 Android special keys , 1 Power button

Extended Storage Micro SD Card Interface,Maximum support 32GB

SIM Card Reader

1 pc,according with ISO7816 standard

Contactless  Card Reader

1 pc,support for ISO14443 Type A/B,

Mifare 1 card,NFC Forum tag types

1 pc,support for ISO14443 Type A/B,Mifare DESFire

card,NFC Forum tag types

Electronic wallet and ID card reader (option)

Printer

58mm high speed thermal printer, the maximum diameter of paper roll is 40mm

Front and Rear cameras

Front-loading 5-megapixel autofocus camera/Rear-loading 5-megapixel autofocus camera

Bar Code Reader

Built-in 5-megapixel autofocus camera can read 1D/2D code

Physical Interface

2-USB Host / 2-Serial Port / 1-Ethernet port / 1-Cash Drawer Port / 1-HDMI / 1-Audio / 1-External Power IN

Power Adapter

DC 12V 3A



Batttery

7.4V 5200mAh lithium-ion battery

Outline Dimension

320mm×215mm×60mm(L×W×H)

Weight

1150g(without battery)

Environmental Requirements

Working temperture:0℃~+50℃
Storage temperature:-20℃~+70℃
Relative humidity :5%~95%(Non condensation)

Foundation Certificate

CE,CCC


Items Specifications
CPUARM Cortex-M3@108MHz
Memorizer1MB Program Flash,8/16MB Data Flash
ScreenOLED 128*64 Lattice monochrome
Keyboard10 Numeric keys , 6 Function keys
Magnetic Card Reader3 rail tracks,support bidirectional card,according with ISO7810,7811standard
IC Card Reader1 pc , according with EMV / PBOC standard , support for CPU card , Memory card
SAM Card Reader2 pcs,according with ISO7816 standard
Contactless  Card Reader1 pc,support for ISO14443 Type A/B,Mifare DESFire card,NFC Forum tag types
Foundation Certificate

Contact EMV 4.3 / PBOC3.0 L1;Contactless EMV 2.5 / QPBOC L1

Contact EMV 4.3/ PBOC3.0 L2;PCI PTS 4.1;

China UnionPay PIN input equipment security certification

Additional Application

Certificate

Contactless Master PayPass / VISA PayWave / QPBOC

China UnionPay accepting terminal product authentication

(The information shown here is indicative only,If there is inconsistency between the specification and the actual product,the actual product shall govern.)
After-sale Services

After-sale Policy:

If you want us to repair the fault terminals, please contact with WAYPOTAT guy to confirm it first. And then you can send them to our HK's address:(before shipment, kindly contact your sales

 Note: 1) All returns must be sent carriage-paid.

       2) Please send the original wrapping with in other parcel in order to avoid that it gets damage.

       3) Do not sent accessories together with your repair (cables, battery, etc.)

After-sale Service

    • Phone support

Technicists provide project inquiry, failure diagnosis and instructive technology service through service hot line.



    • Remote support

When problem can not be solved by phone or there is a complex bug, we will use our remote monitoring center to monitor and diagnose.



    • On-site support

When phone support and remote support can not solve the problem, or customer requests something, after-sale service department will send out professional after-sale technicist and serve our customer on site.



WAYPOTAT Service Promises

Promise 1. After-sale staff gives the quickest reply to customer’s feedback to shorten customer’s waiting time.



Promise 2. Promise to use our best service attitude, and to provide customers standardized service.



Promise 3. During the warranty period, in normal circumstances, provide free parts warranty. Outside the warranty period, only cost a small amount of maintenance fee.(state: physical damage and natural disaster not included)

Company Information

WAYPOTAT Industry Inc. was established in Dec. 2012 by Hongkong Way Po Tat Technology Limited  with a registered capital of one million RMB. Our focus is on research and development ("R&D"), manufacturing, sales and after sales support of industrial mobile devices.  Our products and solutions are widely used in the logistics, retail, manufacturing, medical, and government sectors.



With over 15% of our annual revenue reinvested into R&D, WAYPOTAT has a professional technical team.  Our products and solutions have been successfully deployed in mega projects such as  logistic ,parking  and  warehousing system.



When we first introduced our locally designed Xsmart12 and the PT396 series of wireless mobile intelligent client, we gained recognition as the pioneer and leader in the mobile solutions for the logistics industry in China.  Today, we have added over 10 models of mobile devices to our portfolio, which include the mobile payment client, the handheld data terminal integrated with RFID reader/writer, 1D/2D barcode scanner & wireless communications, the industrial tablet computer and various handheld barcode scanners. We also complement our hardware devices with our complete client-server software systems to offer a comprehensive solution to our clients.



Our manufacturing facility is in ShenZhen, and we have sales and support centers in Singapore, Newzealand, and Brazil.  Using WAYPOTAT as our global marketing gateway, we have over 150 distributors, system integrators, and business partners working closely with us to deliver our products and solutions in over 40 countries in the world.



As the most prominent maker of industrial mobile devices in China, WAYPOTAT always begins at the client's point of view, providing high quality products and value added services to our clients.
