Product Overview
Description
If you feel that this product does not meet your requirements, you can consult our staff, you can recommend or customize the lithium battery protection board you want.
Product Paramenters
Description of application effect
(Battery Management System) BMS can extend battery life and make battery work safely.
This model can be used for solar, LED lights, Emergency lights, Digital Equipment, etc.electric scooter,e-bike,tourisr sight seeing vehicle,electric tricycle,low speed ev,emergrncy ups,solar street light,RV&home energy storage......
Product Description
About your products, just tell us the rated voltage / current or application etc,we will help to recommend the most suitable products for you.
Supply OEM/ODM and custom service
* High quality with smart balance function
* Wholesale price
* ISO9001/ISO14001/CE/ROHS certificates
* Fast deliveryAbout the battery BMS/PCB/PCM
Function:
Supply OEM/ODM and custom service
* High quality with smart balance function
* Wholesale price
* ISO9001/ISO14001/CE/ROHS certificates
* Fast deliveryAbout the battery BMS/PCB/PCM
Function:
Detect and protect the battery from over-charge ,over-dicharge, over-current short-circuit ,temperature detecting protection andauotmatically voltage balance function .
Build with high end electronic components (High End IC and MOSFET ) ,simple structure design will let it have more stable quality working performance , Flexible application ( it can be used for less series battery by leaving some connection pins at empty status ),full set of protection measures let it
works well without any infulence from external unexpected accidents.
Build with high end electronic components (High End IC and MOSFET ) ,simple structure design will let it have more stable quality working performance , Flexible application ( it can be used for less series battery by leaving some connection pins at empty status ),full set of protection measures let it
works well without any infulence from external unexpected accidents.
inform：
Electric Switch, Temperature Switch, Passive Balance, Active Balance, 5V output, NTC and etc., if you need any above accessories, please must to contact our sales fisrt. All items could be customized as your requirements, if without any requests after order placed, we will produce as original.
Mode | LWS-1S5A-012(1S |
PCM Size | L28*W5*T2.5 mm |
battery series | 1S Available |
working current | 5A Available |
Application | LED lights, Emergency lights, Digital Equipment, etc |
Sample | available |
BMS 1S, 5A for LiFePO4 or Li-ion Battery Packs is available
Wiring:
1. First connect the B- of the BMS to the total negative pole of the battery pack;
2.The cable starts from the thin black one connecting B-, the second red wire connects the positive pole of the first string of batteries, and the next string is connected in turn to positive pole of the battery,B-,B1，; then insert the cable into the BMS;
(The maximum number of strings is 1 strings, the example picture is 1 strings)
(Please weld the wires in order and avoid pseudo solder joints.)
3. Connect Charger C-/Load P- with BMS C-/P- (Use larger size wires)
4. Connect Positive Pole: Charger C+/Load P+ with Battery Pack B+ (Use larger size wires) .
1. First connect the B- of the BMS to the total negative pole of the battery pack;
2.The cable starts from the thin black one connecting B-, the second red wire connects the positive pole of the first string of batteries, and the next string is connected in turn to positive pole of the battery,B-,B1，; then insert the cable into the BMS;
(The maximum number of strings is 1 strings, the example picture is 1 strings)
(Please weld the wires in order and avoid pseudo solder joints.)
3. Connect Charger C-/Load P- with BMS C-/P- (Use larger size wires)
4. Connect Positive Pole: Charger C+/Load P+ with Battery Pack B+ (Use larger size wires) .
About your products, just tell us the rated voltage / current or application etc,we will help to recommend the most suitable products for you.
PCM Specifications For 3.7V (1S) Li-ion Battery Packs | ||||||
Model:LWS-1S5A-012(1S) | ||||||
No. | Test item | Criterion | ||||
1 | Voltage | Charging voltage | DC:4.2V CC/CV | |||
Balance voltage for single cell | ||||||
2 | Current | Balance current for single cell | ||||
Current consumption | ≤20μ A | |||||
Maximal continuous charging current | 4A | |||||
Maximal continuous Discharging current | 4A | |||||
3 | Over charge Protection | Over charge detection voltage for single cell | 4.25V±0.025V | |||
Over charge detection delay time | 0.5S—2S | |||||
Over charge release voltage for single cell | 4.05±0.05V | |||||
4 | Over discharge protection | Over discharge detection voltage for single cell | 2.80V±0.08V | |||
Over discharge detection delay time | 10mS—200mS | |||||
Over discharge release voltage for single cell | 3.0±0.05V | |||||
5 | Over current protection | Over current detection voltage | 0.15±0.025V | |||
Over current detection current | 8±2A | |||||
Detection delay time | 5mS—20mS | |||||
Release condition | Cut load,Automatic recovery | |||||
6 | Short protection | Detection condition | Exterior short circuit | |||
Detection delay time | 200-500us | |||||
Release condition | Cut load,Automatic recovery | |||||
7 | Resistance | Protection circuitry（MOSFET） | ≤40mΩ | |||
8 | Temperature | Operating Temperature Range | -40～+85℃ | |||
Storage Temperature Range | -40～+125℃ | |||||
