Product Overview

Description

PVC COATED TARPAULIN



Product Description



PVC coated tarpaulin is the most frequently used material for flexible fabric structures. It is made up of a polyester scrim material, a bonding or adhesive agent, and exterior PVC coatings. The scrim supports the coating (which is initially applied in liquid form) and provides the tensile strength, elongation, tear strength, and dimensional stability of the resulting fabric.

The base fabric's tensile strength is determined by the size (denier) and strength (tenacity) of the yarns and the number of yarns per linear inch or meter. The larger the yarn and the more yarns per inch, the greater the finished product's tensile strength.

The adhesive agent acts as a chemical bond between the polyester fibers and the exterior coating and also prevents fibers from wicking, or absorbing water in a process that could result in freeze-thaw damage in the fabric.



Characteristic:



1. Waterproof
2. Mildew proof
3. Tear resistant
4. Acid resistant
5. Artic flexibility
6. UV treated
7. Fire retardant (B1, NPFA701 etc.)
8. Heat sealable



Specificaitons:



Item	Dates	Unit	Test Method
Item Code	BCT-1000-2020-610	---	---
Item Name	PVC TARPAULIN	---	---
Coating Method	PVC COATED FABRIC	---	---
Color	White, Black, Yellow, Red, Blue, Orange, Green, Gray
Emboss	SUPER GLOSSY OR MATTE	---	---
Base Fabric	POLYESTER FABRIC	---	---
Fabric Density	1000D X 1000D, 20X20 Weaving	Thread/ Inch	DIN EN ISO 2060
Finished Weight	610 (+15)	Gr/m²	DIN EN ISO 2286-2
Fire Retardant	B1, B2, M1, M2, NFPA701, DIN75200	---	---
Thickness	0.5 (+0.02)	mm	---
Composition fabric	128	Gr/m²	---
Composition PVC	482	Gr/m²	---
Total Weight	610 (+15)	Gr/m²	HGT 3050.2-2001
Tear Strength	280 (Wrap)/ 260 (Weft)	N/ 5cm	HG/T 2581.1-2009
Tensile Strength	2350(Wrap)/ 2100 (Weft)	N/ 5cm	HG/T 2580.1-2008
Adhesion	100(Wrap)/ 100 (Weft)	N/	DIN53357
Temperature Scope	-30 to 70	℃	v
Light Fastness	≥6	Grade	DIN EN ISO 877
Width	1.02-3.2	m	---
Roll Length	50 (standard)	m	---
Application	Tent, Truck cover, Side curtain, Inflatable toy





Remarks:



Color, weight, width and softness can be customized per your requests.



(If you have any question please contact me .Free samples can be provided)







Package Details



1. Normal package: PE films+craft paper

2. Hard Tube: package: Normal package+Hard tube



Delivery Details



1.  Shipping type: by sea or by air

2. Delivery time: 20-35 days after signing the contract

3. Delivery port: SHANGHAI port
