JAC HFC1171P3K3A47F CHINA MINI PICKUP TRUCK FOR SALE
JAC heavy-duty truck integrates global advanced technology. According to the different markets, we innovate and optimize our products endlessly and continue to enrich our lineup to satisfy various road conditions and our costumers' demands, enabling JAC heavy truck to become a high-end heavy truck in the international market.
Model
HFC1171P3K3A47F
HFC1254KR1T
HFC1314K1R1LT
Drive mode
4*2
4*4
8*4
Engine
Model
ISDe245 40/ISDe210 40
WP10.340E32
WP10.380 E32
Emission levels
E-4
E-4
E-Ⅲ
Max output power(hp/rpm)
245/2500,210/2500
340/2200
380/2200
Max torque(N·m/rpm)
950/1400,800/1400
1350/1200-1600
1460/1200-1600
Transmission
Model
8JS105TA
9JS150T-B
12JSD200/12JSD200T
PTO
optional QCD45A
optional QH50
/
Rear axle;ratio
457;4.875/5.286
Steyr;4.8
Steyr;4.8
Clutch
Single, dry plate, diaphragm ,power assist
Single, dry plate, diaphragm spring
Single, dry plate, diaphragm spring
Braking system
Dual-circuit air brake
Dual-circuit air brake,WABCO system
Dual-circuit air brake
Main Parameter
Overall dimension(L×W×H) (mm)
8522*2390*3105
10990*2495*3430
11990*2495*3570
Wheelbase(mm)
4800
6000+1350
1900+4500+1350
GVW/GCW(Kg)
16000
35000
30950
Rated load (kg)
9100
22600
17820
Tire
10.00R20, 11R22.5
12R22.5 16PR,12R22.5 18PR,12.00R20
11.00R20,12.00R20
Company Information
CIMC VECHICLE was founded by 1980, having over 63, 000 staff across China, North America, Europe, Asia and Australia. CIMC the biggest truck and truck body manufacturer in China, CIMC is famous in the world!
CIMC China truck supermarket cooperates with all brands of trucks which all produced in China for the GVW>15, 000 kgs heavy trucks, CIMC produces the cargo body or special truck body for the trucks. The CIMC own truck brand is C&C, and cooperate other truck chassis brand which produced in China.
Certifications
FAQ
Q: I want to transport the truck by container, is it ok?
A: Yes, it is ok .But we need take apart the truck.You should reinstall in your country.
Q:How about the quality guarantee and after -sale service?
A: For quality guarate, we give one year guarantee, and with 24hours response principle for better service.
We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.
Q:I want to be your agent in my country , is that ok?
A:It’s ok, If your quantity is big, we will consider. For the first time 50 units is ok.
Q: I want the front two tyres are bias tyre and the rear 9 tyres are radial tyres, is it ok?
A: We can make the tyres as your requirement to suit your country's need.
Welcome to have a visit to our company and factory.
