HD MI to LVDS Board

Features : lcd display circuit board

hd-mi&Analog RGB input.

 Stereo input for PC audio.

 On board 2 x 3 W Class D audio amplifier.

 Remote control support.

 On board LED backlight power supply for small LED panel.

 Dual channel LVDS transmitter,support upto WUXGA(1920x1200).

 Internal power adapter supported.

lcd display circuit board pm390 is small size,  , size is 108.6mm(L)x51.7mm (W) .

One board packaged by antistatic bag, one box carton can put 120pcs .

For program sample testing , we offer board with software according to your screen , and support technology support .

Moq order is 500pcs , delivery time : one month .
