linear peristaltic pump

Product Overview

Description



Technical parameter
    Speed: 1 to 300 rpm, reversible
    Speed resolution: 1 rpm
    Running direction: cw/ccw
    Display: 3-digit LED displays current speed
    Analog interface: Start/stop and cw/ccw control, 0 to 5V, 0 to 10V, 4 to 20 mA and 0 to 10 KHz speed control
    Communication interface: RS485
    Power supply: AC 90 - 260V 50/60 Hz
    Power consumption: < 50W
    Operating condition: Temperature 0 to 40℃ Relative humidity < 80%
    Drive weight: 3.5 kg
    Dimensions (L×W×H): 276×184×175 (mm)
    IP rating: IP 31

Technical Data Sheet

Pump head	model	Available tubing	flow rate range (ml/min)
	YZ15-l3A	13#, 14#, 19#, 16#, 25#, 17#, 18#  wall thickness:1.5mm	0.07-1140ml/min
	YZ25-l3A	15#, 24#  wall thickness:2.5mm	1.7-810ml/min
	BZ25-lA	24#  wall thickness:2.5mm	0.26-780ml/min
