Поставщик печатных плат с линиями SMT, предоставляет услуги по изготовлению на заказ для цифровых устройств IOT BLE
- Category: Double-sided PCB >>>
- Supplier: Shenzhen,Pengzexiang,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
PCB&PCBA Technical
SERIAL | ITEM | TECHNICAL DATA |
| 1 | Product Name | |
| 2 | Brand | Sunsoar |
3 | Layers | 1-28(layers) |
| 4 | Max Board Size | 457 x 610mm |
5
|
Min Board Thickness | 4(layers)0.60mm/24mil |
6(layers)0.80mm/32mil | ||
8(layers)1.00mm/40mil | ||
10(layers)1.20mm/48mil | ||
6 | Min Line Width | 0.10mm /4mil |
7 | Min Line Space | 0.10mm /4mil |
8 | Min Hole Size | 0.20mm /8mil |
9 | PTH Wall Thickness | 0.020mm /0.8mil |
10 | PTH dia tolerance | ±0.05mm /±2mil |
11 | NPTH hole dia tolerance | ±0.025mm /±1mil |
12 | Hole Position Deviation | ±0.05mm /±2mil |
| 13 | Qutline Tolerance | ±0.1mm /±4mil |
14 | S/M Pitch | 0.08mm /3mil |
15 | Insulation Resistance | 1E + 12Ω (Normal) |
16 | Aspect ratio | 10:1 |
| 17 | Thermal shock | 288℃(10 seconds 3 times)/3x10Sec@288℃ |
| 18 | Warp and Twist | ≤0.7% |
19 | Electric Strength | >1.3KV/mm |
20 | Peel Strength | 1.4N/MM |
| 21 | Solder Mask Abrasion | ≥6H |
| 22 | Flammability | 94V-0 |
| 23 | Impedance Control | ±5% |
All of the above description is to demonstrate the ability of our factory, if you
have specific requirements,please contact us.
Company Information
Shenzhen Sunsoar Electronic Co.,Ltd is a professional Printed fast Circuit Board manufacturer. Production bases located in Shenzhen Bao’an.
After years of continued innovation and development, we have now set a PCB Business Unit and an FPC Board Business Unit ,and our production ability has up to 10,000 sqm/month. Manufactured products are widely used in communication apparatus,automobile electronics, computers,medical devices and network devices and consumer electronics class fields.
about us
our factory
Packaging & Shipping
Certifications
FAQ
1. When was your factory built?
Since 2008
2. How many people in your factory?
There are about 80 workers in our PCB factory, and the factory area with 3000 square meters.
The SMT production line have 40 workers, with 1000 square meters.
3. Can you design file from my schematic diagram or real samples ?
Yes, we can, kindly send the details by email, our engineer team will check and contact you in first time.
4. How about your lead time?
1) For single and double layer PCB, 24 hours for quick-turn service, normally 3-4 working days for sample order.
2) For mass production, normally 6-7 working days.
3) For 4 layer PCB, 48-72 hours for expedited service, 6-7 working days for sample order,7-8 days for mass production.
4) For PCB assembly, if all components are available in stock, samples can be sent within 24 hours for quick-turn( urgent) service.
Normally, The estimated delivery date based on the ordering time of all components and components quantity on the boards, Our assembly time around 3-7 days.
