Guide rail fitting sewage pump system for waste water

Product Overview

Description

Guide rail fitting system sewage pump



The model WQ submersible pumps are constructed of rugged cast iron suitable for effluent and sewage  applications. The model  has a  vortex impeller suited for pumpage containing abrasive, stringy and/or suspended solids. Besides it can handle hot water applications up to 248°F.

---

Specifications

• Discharge Size: 2″, 2.5'',3″,4'',6'',8''10'',12'',14'',16'',20'' and 24''


• Range of HP: 1HP to 8000 HP


• Capacity: 10m3/h to 6000m3/h


• Head: 10 to 200 Feet


• Max. solid diameter: 2 1/4″


• Max. liquid temperature:



  • 122°F/40°C (Model 1)


  • 158°F/80°C (Model 2 )


  • 176°F/120°C (Model 3)





---

Key Features

• Air-filled heavy-duty motor  – higher efficiencies


• Built-in motor protection autocut – protects against overheat, out of phase, single phasing and no load


• 60,000 hour bearings – long dependable operation with lower maintenance costs


• vortex impellers – vortex action prevents clogging and handles stringy materials better in applications where problematic clogging can occur


• Large solids handling – able to handle abrasive, suspended solids up to 2 1/4″


• Double mechanical seals – operate in an oil bath away from pumpage providing longer service life and lower maintenance costs


• Available for slide rail installations – to provide easy maintenance for small sump type installations

---

Applications

• Water


• Wastewater


• Drainage


• Effluent


• Hot Water
