New Product Lab Medical Equipment CE Approved 5 DIFF Automatic Hematology Analyser

Product Overview

Description

New Product Lab Medical Equipment CE Approved 5 DIFF Automatic Hematology Analyser

1.3-part differentiation of WBC, 22 parameters, up to 60 samples per hour.

2. Classic fluid pipe design, larger result Linear Dynamic Range.

3.Advanced ARM Intelligent digital processing technology

4.Three independent operation model: Figure button, mouse, international Key-board

5.Low sample volume,10~40uL adjusted. high precision microanalysis.

6.Automatically cleaning sampling probe(inside and outside)

7.10.4” color TFT, all testing parameter displayed simultaneously

8.Large storage capacity: up to 10,000 samples +3 histograms

9.Internal thermal-sensitive printer or external printer

10. RS232 interface, PC connecting

Main Technical Specifications

Methodology: Electrical resistance for counting, hemiglobincyanide method and SFT method for hemoglobin

Parameter: 3-part differentiation of WBC; 20 parameters and 3 color histograms (WBC, RBC, PLT)

Work mode : Single/Double Channel + unique Hemoglobin test system

Sample volume: 9.6μL for Venous and capillary mode, 20μL for prediluted mode

Throughput: More than 35 samples per hour, operatable 24 hours a day, auto sleeping and waking-up functions

Storage: up to 100000 sample results including histograms can be stored, convenient for inquiry and management of history data

Operation langue: English

QC control : X-B, L-J, X , SD, CV %

Refrence Value Setting : Male , Female, Children, Neonate

Input / output : RS232, parallel printer and keyboard

Print : Graphic thermal printer with various printing format,  optional external printer

Temperature : 18℃ - 30℃,wet ≤ 10-90%

Power supply : 220 V ±22 VAC, 50±1Hz

Dimension : 33 CM ( L ) * 38 CM ( W ) * 43 CM ( H )

Weight :  20 KG



Precision

Parameters                 linear range            CV %

WBC( 10 9 / L )              0.0 - 99.9              ≤2%

RBC ( 1012 / L )              0.0 - 9.99             ≤1.5%

MCV ( fL )                  40-150                ≤0.5%

PLT ( 10 9 / L )              0-999                  ≤4.0%

HGB( g/L )                 0.0-300.0               ≤1.5%

Parameters

WBC, Lymph#, Mid#, Gran#, Lymph%, Mid%, Gran%, RBC, HGB,HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV,PDW,PCT,L-PCR



3 –histograms : WBC,RBC and PLT
