1. A high degree of automation PLC + HMI, convenient parameter settings.
2. High efficiency ,save lab-our,, a person operating two sliding table.
3. Save space,structure is compact , cover less area.
4. Accurate, with high precision positioning system. And use this device to easily accurate registration.
5. High sensitive spark protection when sparks produced, it can quickly cut off high frequency oscillation power, protect the mold and material.
6. Without high frequency radiation,with good shielding device.
7. Easy to change the mold, with safe and fast change mold lifting device.
8. Safety design is reasonable, the slide will not pressure the finger.
9. Stack up and down slider design , sometimes can share a mold and a high mold cost can be saved.
10. With 30 tons of pressure,which can be embossed immediately after cutting,products around the bright and clean,embossed molding effect is good .
Model
YJ-ZR-8KW
YJ—ZR-10KW
YJ-ZR-12KW
YJ-ZR15KW
High frequency power
8KW
10KW
12KW
15KW
power
8KW
10KW
12KW
15KW
Output power
12KVA
15KVA
20KVA
30KVA
Above electrode size
300*500mm
350*550mm
400*600mm
400*600mm
Frequency
27.12MHZ
27.12MHZ
27.12MHZ
27.12MHZ
Oscillation tube
7T69RB
E3069
E3130
8T85
Cutting maximun pressure
15T-60T
15T-60T
15T-60T
15T-60T
Machinery net weight
1640kg
1640kg
1640kg
1640kg
Machinery gross
1760kg
1760kg
1760kg
1760kg
Packing size
2450*2100*2550mm
2450*2100*2550mm
2450*2100*2550mm
2450*2100*2550mm
Scope of Application
Packaging & Shipping
Company Information
Dongguan Yongjia Machinery Equipment Co.,Ltd, founded in 2003, is a large professional high frequency equipment factory, with strong technical capacity, advanced production equipment, experienced team and excellent service, using scientific management system, strictly follow production standards and testing standards, our products quality and service have been widely recognized by the industry, with many years production practice and technology development, we are a leading company in the industry with complete high frequency equipment product lines; our products include automatic high frequency plastic packaging production line, digital products hot pressing equipment, automotive interior components welding equipment, membrane structure canvas welding machine, industrial belt skirt baffle welding machine, automatic medical bag high-frequency welding machine and other kinds special high frequency welding machines; automatic high-frequency welding equipment, automatic cylinder production line, soft line glue box machine and hundreds of products. At the same time, we provide customized non-standard and special equipment, according to the needs of different customers, has a strong team of foreign trade business, the products are exported to Germany, Russia, Brazil, America, Southeast Asia and are hot selling in domestic market too. Yongjia enterprise, based on out superb technology and complete, high quality service, provides customers great service.
Welcome to visit our plant!
FAQ
Trade patterns
1. Lead time: 5-15working days after receive deposit
2. MOQ: 1 set.
3.30% deposit+ balance payment before delivery by T/T;L/C
4. Loading Port:Shenzhen
Import Process
1. We will prepare goods after receive deposit
2. We will send goods to your China warehouse or shipping company .
3. We will give you tracking number or Bill of loading when your goods is on the way
4. Finally your goods will arrive your address or shipping port
Good Quality Product
Good quality product and strict quality control department before shipping,quality is our life,
all of our machine meet CE standard.
Q: why you choose us?
1.we are manufacturer and professional in manufacturing welding machines for more than 10 years experience.
2.provide customized services for special orders according to customer requirement
3.no lowest price but always value for money
Q: What aftersales service or any question about products?
A:Our warranty is 1 year, all machine part can be replaced for free within 1year if broken(not including man made).
