BLS HV7025MG 25kg high voltage brushless standard large rc car servo motor

Product Overview

Description



BLS-HV7025MG 25kg high voltage brushless standard large rc car servo motor







 Feature:

• High performance digital high voltage brushless standard servo



• High-precision Taiwan-made aluminium gears with hard anodizing



• High quality brushless motor



• Full CNC aluminium Shell structure



• Dual ball bearings



• Waterproof



Specifications:

• Dead band: 1μs



• Working frequence: 1520μs / 330hz



• Motor: Brushless Motor



• Operating Speed (6.0V): 0.152sec/60°



• Operating Speed (8.4V): 0.123sec/60°



• Stall Torque (6.0V): 20.25 kg.cm (281.22oz/in)



• Stall Torque (8.4V): 25.31kg-cm (351.47 oz/in)



• Dimensions: 40.5X20.5X36mm/1.59X0.80X1.43in



• Weight: 70.1g (2.47oz)



• Connector Wire Length: JR 265 mm (10.43in)



• Bearing: 2BB



OEM/ODM Order question




* For the SERVOS please let us know your requirements:                                              1. Which Area you used for? RC Servo or Industry Servo?   2. What's your expected torque?   3. What's your expected speed?   4. Do you have serice life requirement?   5. Your working voltage please.   6. Do you have location dimension limited? If so, please let us know the maximum size.   7. Do you need it waterproof?   8. How many qtys you need?   9. Other requirements if you need, for example, wire length, connector types and so on. * For the MOTORS please let us know your requirements:   1. Please choose inrunner motor or outrunner motor you need.   2. Do you have motor diameter and length limited?   3. What working voltage you will use for this motor?   4. What's your expected rated power?   5. What's your expected RPM?   6. You battery pack can bear how high peak current?   7. You estimated yearly sales qty?   8. Do you need the speed controller as well or if you have yours,let us know the spec.   9. Other requirements if you need, for example, wire length, connector types etc. Contact us directly via Trade Manager or send us email, we will reply ASAP in 24 hours. Below our custom made motors for other clients for your information.



Packing:



Certificate:





Note:

1. Small Order Welcome
2. Can Do OEM & Flexible Customized Design
3. Competitive Price
4. Good After-sales Service
