LPG series Blood cell protein solution spray dryer
- Category: >>>
- Supplier: Changzhou Shinma Drying Engineering Co. Ltd.
Share on (60631196309):
Product Overview
Description
Blood Cell Protein Spray Dryer Description
The spray drying is the widest used technology in the liquid shaping technology and in the drying industry. It is most suitable for producing powder, particle, or block solid products from materials of solution, emulsion, soliquoid and pumpable paste states. Therefore, when the particle size and distribution of the final products, their residual water contents, the stocking density and the particle shape meet the precision standards, the spray drying is one of the most desired technologies.
Blood Cell Spray Dryer Design Condition
1,Liquid condition
Initial moisture content: 78%
Water evaporation rate: 500Kg/h
Liquid material temperature: 240℃
Exhaust temperature:90℃
2,Technical condition
Contact way of droplet and hot air: parallel
Heat source and heating way: natural gas and hot air furnace
Product gathering way: two cyclone + water scrubber
Product collecting way: air dehumidifier
System manufacturing material: refer to following detailed machine configuration
Blood Plasma Spray Dryer System Description
Machine model: LPG 500 Spray Dryer Unit
Heating system: Indirect Heating Natural Gad Hot Air Furnace
Fine powder gathering system: cyclone + bag duster
Product collecting system: freezing & dehumidifying
Circulating system: blower+ exhaust fan open recircle
Firing system: primary + middle efficiency+ HEPA
Feeding system: screw pump adjustable
Control system: Digital instrumentation display temperature, pressure, pressure, touch-screen animation flow chart, focused set of parameters, PLC technology to automatically track the control variables of fuzzy parameters, etc.
Blood plasma Spray Dryer Technical Parameter
|
Water evaporation |
500Kg/h(max) |
D/H |
5.15M/11M |
|
Operation temperature |
Inlet 240℃/Outlet 95℃ |
Atomizer LPG-500 |
rotate speed:15500r.p.m disk:160mm |
|
Installed power |
dynamic 60KW |
||
|
System heat |
80×104Kcal/h |
Compressed air consumption |
2.0 m3/min(0.6MPa) |
|
Drying form |
Open circulation |
Feeding way |
Screw pump |
|
Hot air contact way |
Parallel |
Heat souce |
natural gas |
|
Product collect way |
Cyclone +bag duster |
Atomizing way |
centrifugal atomizing
|
