Guangzhou professional Speaker supplier 10 inch pa coaxial speaker/professional speakers
- Category: >>>
- Supplier: Guangzhou Merry Audio Intelligent Technology Co. Ltd.
Share on (60631830239):
Product Overview
Description
Guangzhou professional Speaker supplier 10 inch pa coaxial speaker/professional speakers
1- 65 mm/2.5 inch voice coil;
2- Ferrite Magnetics;
3- Die Cast Aluminum frame;
4- 400W high power speaker driver;
Product Description
NOMINAL SPECIFICATIONS |
Nominal Diameter 250mm (10 in) |
Overall Diameter 250mm(10 in) |
Bolt circle diameter 261mm |
Baffle Cutout Diameter 245mm |
Depth 145mm |
Net Weight 5.65kg |
Shipping Box 365×365×210mm |
Shipping Weight 6.45kg |
TECHNICAL PARAMETERS |
Nominal lmpedance 8Ω |
Minimum lmpedance 6.5Ω |
AES Power Handing(1) 200W |
Maximum Power Handling(4) 400W |
Sensitivity(1W/1m) 95 / 104dB |
Frequency Range 40-1600Hz |
Voice Coil Diameter 65mm(2.5 in) |
Winding Material(LF) CU |
Winding Material(HF) AL |
Diaphragm Material Polyester/Titanium |
Dispersion Angle 70 |
Recom. Crossover 1.2kHz |
Magnet Ferrite Ring |
Demodulation NO |
Suspension(5) M Roll |
THIELE & SMALL PARAMETERS |
Fs 63Hz |
Re 5.5Ω |
Qes 0.44 |
Qms 7.9 |
Qts 0.42 |
Vas 25 dm³ |
Sd 320cm² |
Xmax 5.5mm |
Mms 36.5g |
Bl 13.4N/A |
Cms 0.08mm /N |
η(Eta Zero) 1.4% |
EBP 94Hz |
