Seven Layers Coextrusion PE Stretch Film Machine PE Stretch Film Extrusion Line PE Stretch Film Extruder

Product Overview

Description

Seven Layers Coextrusion PE Stretch Film Machine



This stretch film machine mainly applies LLDPE and adopts several kinds of resins to manufacture

single/double-side self-adhesive three-layer stretch wrapping film by extruder.





The multi-layer co-extruded stretch film has better tensile strength, puncture resistance and

impact resistance. Its good shrinking memory and self-adhesive function can make goods

integrity to prevent them from loosening and collapsing during transportation and being polluted

by dust. The transparency and tensile strength of this product can make the packaging

beautiful, economical and practical.





The film can be widely used for wrapping of palletized goods. It's a good substitute for hot

shrink packaging film in transportation.





Model	1800mm	2400mm
Screw diameter(mm)	80/125/80	90/135/90
L/D ratio of screw	32:1	32:1
Width of die head(mm)	1800	2400
Width of finished products(mm)	1500	2000
Thickness of finished products(mm)	0.017-0.050	0.017-0.050
Structure of film layers	A/B/C	A/B/C
Max extrusion capacity(kg/h)	450	600
Design line speed(m/min)	280	280
Total power(kw)	380	500
Overall dimensions(L×W×H)(m)	13×6×5.5	15×8×5.5
Weight(T)	28	35
