lab type softgel capsule filling machine , soft gelatin encapsulation machine for gels, serums, creams, pastes, oils
- Category: Pharmaceutical Filling Machine >>>
- Supplier: ZHEJIANG LEADTOP PHARMACEUTICAL MACHINERY CO. LTD
Share on (60633834691):
Product Overview
Description
Softgel Encapsulation Machine
Application
Softgel encapsulation machine can quantificationally inject the oil, mixing suspension and pasty mass into the capsule to form all kinds of softgel encapsulation with different size, shape and color. Because of the merits of high speed disintegration, easy to oral, hard to oxygenation, easy to store and take, the softgel encapsulation is welcomed by more and more customers. Owing to the high productivity, charging exactly, quality stabilization, high finished product rate, it is favoured by more and more manufacturers and used in the fields of medicine, health products, cosmetic and game-color ball and so on.
This product has passed provincial-level appraisal of new product and the certification of EU adopted two items of patent technology in manufacturing with exquisite workmanship.
This product has passed provincial-level appraisal of new product and the certification of EU adopted two items of patent technology in manufacturing with exquisite workmanship.
Features
1. Strong product capacity, it can produce 300 million granules (No.8 oval shape, 3 revolutions/minute, 24 hours / day, 300 days/year).
2. Injecting medicine part adopts advanced linearity driving system, and it makes sure that the precision of charging and filling is less than 2%.
3. Capsule package rate is up to 98%.
4. The gelatin ribbon is lubricated by fine oil supply technology in order to lower the consumption of lubrication oil. The ribbon is lubricated by vegetable oil, so the capsules produced is free of wash.
5. High quality capsule deferent equipment adopts food conveyer belt authorized by American standard, without poison and adhibition and easy to clean.
6. Optimized designed mould is made of high quality aviation alloy material by high precision numerical control process to insure the mould's service life.
7. Advanced process and assembly technics make the complete appliance quality stabilization , high working rate, and good shape pill.
8. Adopt automatic system project of supplying capsule and material to reduce workers' labor intensity and improve the working environment, which accords with the requirement of GMP.
9. The liquid level in the gelatin box is fixed automatically in the constant position, and the centigrade mater display the thickness of rubber, which is easy and accurate in adjustment.
10. The power of main motor is 1.5KW, which can avoid the phenomenon of insufficient driving power when the content is rather thick ( take 185 model for example).
11. Adopt the nonpoisonous materials to human body or now dropping matters into medicine liquid in this machine and medicine liquid, and the touching parts for gelatin.
2. Injecting medicine part adopts advanced linearity driving system, and it makes sure that the precision of charging and filling is less than 2%.
3. Capsule package rate is up to 98%.
4. The gelatin ribbon is lubricated by fine oil supply technology in order to lower the consumption of lubrication oil. The ribbon is lubricated by vegetable oil, so the capsules produced is free of wash.
5. High quality capsule deferent equipment adopts food conveyer belt authorized by American standard, without poison and adhibition and easy to clean.
6. Optimized designed mould is made of high quality aviation alloy material by high precision numerical control process to insure the mould's service life.
7. Advanced process and assembly technics make the complete appliance quality stabilization , high working rate, and good shape pill.
8. Adopt automatic system project of supplying capsule and material to reduce workers' labor intensity and improve the working environment, which accords with the requirement of GMP.
9. The liquid level in the gelatin box is fixed automatically in the constant position, and the centigrade mater display the thickness of rubber, which is easy and accurate in adjustment.
10. The power of main motor is 1.5KW, which can avoid the phenomenon of insufficient driving power when the content is rather thick ( take 185 model for example).
11. Adopt the nonpoisonous materials to human body or now dropping matters into medicine liquid in this machine and medicine liquid, and the touching parts for gelatin.
Main Technical Data
ITEM/MODEL | LTRJ-110 | LTRJ-200 | LTRJ-250 | LTRJ-300 |
Rotary speed of die roll | 0-7rpm | 0-5rpm | 0-5rpm | 0-5rpm |
Supplying Volume for flow single-pillar pistol | 0-1ml | 0-2ml | 0-2ml | 0-2ml |
Difference among filling volume | ±2% | ±2% | ±2% | ±2% |
Power for whole machine | 2.3KW | 17 KW | 17 KW | 17.6KW |
Power supply | 8 | 380V 50HZ | 380V 50HZ | 380V 50HZ |
Dimention | 1250×900×1820mm | 2420×1180×2210mm | 2420×1180×2210mm | 2420×1180×2210mm |
Weight of whole machine | 600Kg | 1800Kg | 1800Kg | 1900Kg |
Details Images
Products
Company Profile
Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange everything for you!
Any other doubts about our machine, please feel easy to contact with us.
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange everything for you!
Any other doubts about our machine, please feel easy to contact with us.
