8 inch high definition HMI 1024x768 dost matrix tft smart terminal lcd module for IOT embedded technology

Share on (60634236187):


Price:

Quantity:


Product Overview

Description


8 inch high definition HMI 1024x768 dost matrix tft smart terminal lcd module for IOT embedded technology



Product Description


Size: 8 inches
Resolution: 800x600 dots matrix
Active view area: 162x121.5mm
View display area: 163.5x123.5mm
Module size: 199.4mmx148.9mm
Height: 26.5mm
Display color: 64K colors
LED backlight type: LED
Brightness: 250cd/m2
View angles L/R/U/D: 70/70/50/70°
Operate temperatures: -20~70°C
Storage temperatures: -30~80°C
Picture download mode: USB download mode


Functions:
Sets current palette
Sets the character display spacing
Takes a color from specific location
Cursor display
Text display
Chooses the character library display
Character zoom in display
Set/cancel the limitation for textbox
Display point
Line display
Line chart display
Ellipse and ellipse area operate
Circular curve display
Rectangle and rectangular region display
Dynamic curve display
Clear full screen
Picture/icon display and more





Selling Point





Support RS232, RS485, USART (3.3V TTL) interface, baud rate adjustable 1200bps-115200bps


Wide input voltage VDD (5V, 9V-26V)
Support RTC Real-Time Clock
Built-in 4-wire resistive touch screen controller
Supports RGB display
Built-in 10W stereo power amplifier, support (mp3, wav and other audio file formats)
Support for custom voice recording
Support to transmit images in real-time display (embedded video decoder)
Support SD card
Comes with 2Gbit or 4Gbit nand flash
Support USB picture download
Multi-page memory
Color Depth: 65K colors


Drawing for 8 inch high definition HMI 1024x768 dost matrix tft smart terminal lcd module for IOT embedded technology


8 inch.JPG








Product Certificates


    8 inch high definition HMI 1024x768 dost matrix tft smart terminal lcd module for IOT embedded technology


8 characters 2 lines lcd module certificates.png





Our Services


Our advantage and service


15 year's design,manufacture and sales experience
300+ models available,custom orders welcome
exporting to 100+ countries
Free 1-year maintance


Free sample for some styles


Our equipment.png





Product usage


Shenzhen Brilliant Crystal technologic Co.,ltd  lcd module are widely used in Healthcare Biomedical Instrumentation,and clinical diagnostics,Wind Sensors for Measurement,Control, Alarm, Internet Access,metering pumps and dosing systems,water treatment ,charging pile and car beauty equipment and Industrial control equipment, instruments and meters, bank terminal and so on .










Contact Us


Shenzhen Brilliant Crystal Technologic Co.,ltd


Bella Zou


Skype:cjsz2002


QQ:2829642402


cjsz2002#hotmail.com


Celand whatsapp:+86-15889302786


Tel:+86-0755-29485608


Website:www.cjlcd.com  & www.cj86.com


              https://szcmlcd.1688.com/





Related Product





8 inch high definition HMI 1024x768 dost matrix tft smart terminal lcd module support RS232.RS485.TTL with 4 wire touch panel
























































































































Display contentModel No.Outline size
L x W x H (mm)
V.A
L x W(mm)
Dots Size
L x W(mm)
VOltage     Interface
480x272RGBCJS04301120.4x68.6x8.098.5x57.30.066x0.1985V/9V-26VRS232/RS485/TTL
800x480RGBCJS05001143.5x80.9x17.5109x65.80.045x0.1355V/9V-26VRS232/RS485/TTL
640x480RGBCJS05602143.5x105x17115.9x87.670.0588x0.17645V/9V-26VRS232/RS485/TTL
800x480RGBCJS07001190x112x18154.9x93.90.0635x0.19055V/9V-26VRS232/RS485/TTL
800x480RGBCJS07002190x112x18155.9x88.30.0635x0.19055V/9V-26VRS232/RS485/TTL
1024x600RGBCJS07006190x106.6x37.5156.2x92.60.0635x0.19055V/9V-26RS232/RS485/TTL
800x480RGBCJS07008203x112x21155.9x88.30.0635x0.19055V/9V-26VRS232/RS485/TTL
800x600RGBCJS08001199.4x148.9x15163.5x123.50.0675x0.20255V/9V-26VRS232/RS485/TTL
1024x768RGBCJS08003199.4x148.9x37.5163.5x123.50.0675x0.20255V/9V-26RS232/RS485/TTL
1280x800RGBCJS10101248x150.7x37.5219.46x138.10.0635x0.19055V/9V-26RS232/RS485/TTL
800x600RGBCJS10401247.5x176.8x16211.2x158.40.264x0.2645V/9V-26VRS232/RS485/TTL
800x600RGBCJS10402247.5x176.8x16211.2x158.40.264x0.2645V/9V-26VRS232/RS485/TTL
