factory hot sales dahua dvr comparing to hikvision MDVR with 720P/960P/1080P
- Category: >>>
- Supplier: Dongguan Fuzeer Electronic Technology Co. Ltd. [Guangdong China]Dongguan
Share on (60635801465):
Product Overview
Description
Product Description
MAIN FEATURES
-CMSV6 Client Platform;
-Supports 3G 4G/WIFI for video files download (Optional);
-Video files can & alarm log can be downloaded remotely;
-4ch/8ch AHD D1/720P/960P/1080P optional;
-Supports SD Card 128GB & HDD(maximun 2TB) for main recording
-Supports USB mouse operation
-Supports USB2.0 high speed for video files' backup
-Support PC and mobile(Android and iPhone) client remote monitoring
-Integrated with G-sensor,support motion detection
-Via 2x RS232,2x RS485 interface, can be integrated with oil sensor/TPMS/Fatigue driving/Passenger counting system;
-Working temperature -40~85C;
-Size: 158(W) x198(H) x65(D) mm,Weight: 1850g
SPECIFICATIONS
Item | Introduction | |
Operating system | Linux (2.6) | |
Video compression format | H.264 main profile. DSP high-performance processor | |
OSD | Support GPS, time, date, vehicle ID etc. in video | |
GUI | OSD interface | USB mouse/remote control |
Videoandvideosystem | Video input | 1~8CH CVBS video input, 1.0Vp-p, 75Ω |
Video output | 1CH SD CVBS video output, 1.0Vp-p, 75Ω | |
Preview | Support 1CH and 4CH | |
Resolution | CIF,HD1,D1,720P,960P,1080P optional | |
Video quality | Quality 1~4 optional, quality1 is highest, quality4 is lowest | |
Recording Rate | PAL: 100f/s , CCIR625 line,50 fields NTSC: 120f/s, CCIR525 line,60 fields CIF: 256Kbps ~ 1.5Mbps, quality 1~4 optional HD1: 600Kbps ~ 2.5Mbps, quality 1~4 optional D1: 800Kbps ~ 3Mbps, quality 1~4 optional 960H: 500Kbps ~ 4Mbps, 8 levels recording rate optional 720P: 800Kbps ~ 6Mbps, 8 levels recording rate optional | |
Videostreaming | ISO14496-10 standard | |
Recording mode | Automatic recording, timer recording, alarm recording | |
Audio | Audio input | 4CH input |
Audio output | 1CH output | |
Compression format | G.726, Rate 5KB/s | |
Alarm | Alarm input | 6CH alarm input(Level input) |
Alarm video file begins to be saved for 10 seconds before alarm, and the time of alarm video file can be set from 30 to 1000 seconds. | ||
Alarm output | 1CH alarm output(Relayoutput) | |
Communication interface | RS232,RJ45 10M/100M adaptivenetwork interface | |
GPS ,G-sensor | Support built-in G-sensor and GPS | |
Video storage | SD card /Hard drive | 256GB & 2TB HDD |
Firmware upgrade | Remote upgrade/SD card/ hard drive upgrade | |
Fileformat/system | FAT32 | |
Video playback | Video search | Search video files according to recording time, recording mode (alarm, normal) and video storage device etc. |
Playback | Maximum support 4CH/8CH simultaneous playback, and analyzevehicle information, support fast forward, rewind, play and pause | |
Support 2/4/8/16 times fast forward and rewind | ||
Power | Power management | 1, Key start/shutdowm DVR: Start/shutdowm DVR according to vehicle key signal, it can also be set to delay shutdown. 2, Timer start/shutdowm DVR. |
Inputvoltage | DC:+8V ~ +36V | |
Outputvoltage | +12V*2A;+5V*0.5A | |
Power-downprotection | UPS technology can save complete video files and ensure those files are not damaged when power-down suddenly. | |
Powerconsumption | Normal operation<10W; Standby<0.5W | |
Work environment | Temperature | -40°C ~ +80°C |
Humidity | 20% to 80% | |
Security management | Passwordaccess | User password and administrator password |
Client Platform
Realtime monitoring & Positioning
Data report
Electronic Fense
