DH80 mirror Label Rule 0.45 x 8 golden color extremely sharp and much longer cutting life

Product Overview

Description

♦ Material

premium imported steel as material, offering higher precision upto +-0.01mm

The higher precision is, the shorter time for adjusting the cutting machine, the smaller machine wear, the faster production, the better cutting effect. Especially the labels cutting, if lower precision, it's completely not qualified to work.



♦ Common Size

size	strips packing	coils packing
0.45 x 5.3 x 915mm	100 pcs/box	100 m /coil
0.45 x 7.0 x 915	100 pcs/box	100m/coil
0.45 × 8.0 × 915	100 pcs/box	100m/coil
0.45 × 9.5 × 915	100 pcs/box	100m/coil
0.45 x 12.0 x 915	100 pcs/box	100m/coil





♦ Hardness

HRC 36-38 (soft)

HRC 39-41 (medium hard)

HRC 42-44 (DH80)



♦ Cutting Bevel

center bevel / CB







♦ Edge Type

grinded edge.

The German grinder for grinding the edge, very sharp and lower friction. Furthermore, the mirror procession technology greatly reduce the burrs at the edge tip.



♦ Edge Angle

42 degree



♦ Application:

 Die cutting the labels, trademarkes, seals, adhesive paper and ect...
