Metal sheet plate bending machine with reasonable price

Product Overview

Description

Metal sheet plate bending machine with reasonable price ,

Product Introduction:

This folding machine can be used to fold the metal sheets into boxes and pans of different sizes ,

Also used for ventilation,cases,trays,kitchen,furniture and so on .

We can design and produce any models according to the sizes forwarded by customers,

Normally,

customers can choose the machine model according to the material thinkness ,

we can produce any model or non-standard products according to customer's special requirement.

1. Heavy duty steel fabricated frame provides accurate folding,

2. Extended fingers allows bending of pans or boxes to a depth of 200mm,

3. Machine equipped with a graduation ruler on both sides,

readout eliminates the bend angle guess work,

4. Optional ground segmented fingers can be repositioned to suit many applications,.

5. Quick action beam adjustment for varying material thickness,

6. Includes rear manual back gauge.

Optional Specifications:

model	folding  angle	weight (kg)	folding  thickness(mm)	folding  length(mm)	size (L*W*H)(mm*mm*mm)
1.5*1300	60º-180º	360	0.3~1.5	1300	1980*800*1320
1.5*1500	60º-180º	380	0.3~1.5	1500	2180*800*1320
1.5*2000	60º-180º	440	0.3~1.5	2000	2680*800*1320
1.5*2500	60º-180º	560	0.3~1.5	2500	3180*800*1320
1.2*3000	60º-180º	680	0.3~1.2	3000	3680*800*1590
