High Quality High Pressure Diesel Water Chemical Manufacturers Hand pump

High Quality High Pressure Diesel Water Chemical Manufacturers Hand pump

Hand pumps are manually operated pumps; they use human power and mechanical advantage to move

fluids or water from one place to another. They are widely used in every country in the world for a variety of

industrial, marine, irrigation and leisure activities. There are many different types of hand pump available,

mainly operating on a piston, diaphragm or rotary vane principle with a check valve on the entry and exit

ports to the chamber operating in opposing directions. Most hand pumps have plungers or reciprocating

pistons, and are positive displacement.

Specifications:

Material: PPS, 304SS spout, tube.
Capacity: 1 Liter per stroke.
Applicable Drum: 5,15,30,55 gallon containers.
Applicable Liquids: Used for weak / strong-base acid and alkali liquids-a model providing the hightest oil-pumping volume amongst models of kind (one liter per rotation; not designed for viscous liquids).
Packing: 4pcs/ctn, N.W: 19kgs / G.W: 21kgs / CUFT: 2.7'

Product ID	RP-32 / RP-32H
	PR-32-1
	RP-32-1H
	RP-32-2 / RP-32-R
Name	High Flow Pump
Specifications	*This versatile drum pump is suitable for the Transfer of low, viscosity fluids such as Gasoline, Kerosene, Diesel, machine oil, etc. *Counterclockwise or clockwise for discharging or suctioning freely. One liter per rotation and 100 liters per minute. PR-32: Vertical conveying distance 15M, PR-32-1: Vertical conveying distance 15M, horizontal conveying distance 50M. PR-32-1H: Vertical conveying distance 15M, horizontal conveying distance 50M. PR-32-2: Vertical conveying distance 15M, horizontal conveying distance 50M. RP-32: With 1 meter tube, PE hose 5pc / ctn / 27.5 / 29 kgs / 3.2'     Applicable Drum: 15,30 and 55 gallon containers RP-32H: With 1 meter tube, PE hose, Zinc Alloy nozzle. Fastener features. 5pc / ctn / 27.5 / 29 kgs / 3.2'     Applicable Drum: 15,30 and 55 gallon containers PR-32-1: With 1 meter tube, PE hose, level spout 5pc / ctn / 29 / 31 kgs / 3.2' Applicable Drum: 15,30 and 55 gallon containers RP32-1H: With 1 meter tube, PE hose, Steel  level spout 5pc / ctn / 29 / 31 kgs / 3.2' Applicable Drum: 15,30 and 55 gallon containers PR-32-2: with 2pcs suction tube, black rubber hose, level spout 3pc / ctn / 24 / 26kgs / 4.7' Applicable Drum: 15,30 and 55 gallon containers. PR-32-R: with PPS body, 304SS spout, tube, PE Hose. 4pc / ctn / 19 / 21kgs / 2.7' Applicable Drum: 5,15,30 and 55 gallon containers. 1 liter / rotation Gallon containers.
Features	Sample Purchase.
Order Information	Minimum Order: Negotiable EXW TAIWAN

ITEM	PCS/CTN	N.W.(kgf)	G.W.(kg)	CUFT	C.C/ Rotation	Available/Gallon Drum
RP-32	5	29	31	3.2	1000	15,30,55
RP-32H	5	29	31	3.2	1000	15,30,55
RP-32-1	5	29	31	3.2	1000	15,30,55
RP-32-1H	5	29	31	3.2	1000	15,30,55
RP-32-2	3	29	26	4.7	1000	15,30,55
RP-32R	4	19	21	2.7	1000	5,15,30,55

Catalogs Images

 Jaan-Huei Industrial Co., Ltd CASH has wider product ranges in
"high flow pump, chemical piston pump, plastic rotary pump, plastic pump, lever action drum pump, aluminum rotary pump, metal rotary pump, piston pump, water pump, syphone pump, metal piston pump and a range of spares and accessories and related products.

Our Company

Jaan-Huei Industrial Co., Ltd for over 26 years we have been professionally manufacturing High Flow Pumps, Ad Blue pump, Piston Pump, Lever Action Drum Pump, High Quality Chemical Piston Pump, Plastic Rotary Pump, Drum Pumps,Water Pumps Our main markets are North America, Germany, and Japan.
If you have any questions, please feel free to contact us.We will reply to your questions as soon as possible.We have had a factory to produce all kinds of manually operated rotary pumps in Taiwan since 1988. Our products are exported to many countries in Asia, Europe and the Americas.
Jann-Huei's production capacity is adequate to guarantee a stable supply, and we are confident that you will find our prices attractive.

Jaan-Huei Industrial Co., Ltd has obtained the patent and trademark from the USA, Taiwan, China, Europe.

Jaan-Huei Industrial Co., Ltd is equipped with high tech, advanced, computerized and self-inspection machineries, manufactures various different parts in house to make sure the built-in quality and dependable performance.
