16 inputs Professional H.265 H.264 HD SDI IPTV Video Encoder SDI to IP streaming UDP RTP RTMP
- Category: >>>
- Supplier: Shenzhen Tbs Technologies Ltd.
Share on (60639595546):
Product Overview
Description
16 in 1 Professional H.265/H.264 HD-SDI Video HTTP/UDP/RTMP Encoder
(TBS2630-SDI)
TBS2630-SDI is a professional 16 in 1 HD-SDI video encoder, which equipped with 16 SDI inputs and dual IP Stream outputs. It supports MPEG-4 AVC/H.265/H.264 High Profile code format input and dual stream H.264 format, audio ACC format output. The HD-SDI Video Encoder is compatible with protocol of HTTP, UDP, RTSP, RTMP, and ONVIF.
TBS2630-SDI can be widely used in variety of digital distribution systems and IPTV solutions.
- Support 16 or 8 HD-SDI inputs.
- Support multiple equipments display on a computer simultaneously
- Support direct network connection without HD capture card
- Support H.264/AVC high profile level 4.0 video encoding
- Support MPEG1 Layer 2 (HE-AAC (V2) or LC-AAC optional) audio encoding
- Support VBR or CBR video bitrate mode
- Support 720P, 1080I, 1080P HD video format
- Support IP Output MPTS and 8 SPTS
- Support IP null packet filter
- Real-time output bit-rate monitoring
- Update device through Web UI.
- Less than 6W Power consumption,
- Compliant with HTTP/RTSP/RTP/RTMP/UDP protocols
Input | |
Video Input | 8/16 x HD-SDI |
Audio input | SDI embedded audio |
AC IN | 110V~240V |
AC rate | 60/50Hz |
Output | |
DC output | 12V/12.5A |
Power Dissipation | 96W |
Vedio | |
Resolution | 1920×1080_60i/60P, 1920×1080_50i, 1280×720_60p, 1280×720_50p and below |
Encoding | H.265/H.264/AVC Main Profile/High Profile , Audio AAC |
Data Rate | 16KBIT/S~12MBIT/S |
Rate Control | CBR/VBR |
GOP Structure | IBBP |
Advanced Pretreatment | De-interlacing, Noise Reduction, Sharpening |
Audio | |
Encoding | AAC, MP3 |
Sampling rate | Auto |
Bit-rate | 32K/48K/64K/96K/128K/160K/192K |
Sampling precision | 24 bit |
Data Rate | 64Kb/s ~ 384Kb/s |
System | |
WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN7 64; LINUX | |
Ethernet/RJ45 | 1000 Base-T Ethernet interface |
Control Interface | Web |
Protocol | HTTP, UDP, RTSP, RTMP, ONVIF |
Others | |
Dimension | 482mm*320.2mm*108mm |
Net weight | 7.5kg |
temperature | -20℃+ 60℃ |
