YMQ 115 hydraulic paper label die cutting machine

Product Overview

Description



YMQ-115 hydraulic paper label die cutting machine



Which function of die cutting machine have?



YMQ series brand die cutter is mainly aimed to various different shape brand, such as various wine, food and drink label shaping die cutter.



Which fields of die cutting machine apply in?

Widely applied to cut various size playing card, aluminum plastic, New year card, instant noodles, note book. Credit card, drop and handbook etc, and various special shape children reading book.



Which advantage of die cutting machine have?

This machine adopts hydraulic pressure system, work stability and crudity, the die cutting products surface is smooth, and the size is unified and regular with higher efficient. There are photo electricity eye in left and right with safer use; the charge bench can do front & back and integrate adjustment, with more convenient use.





Which type fits for your requirement?



Main Technical Parameter of Die Cutter:
Model	YMQ-350	YMQ-260	YMQ-200	YMQ-115
Max.Die-cut size	380*300mm	300*240mm	220*220mm	140*140mm
Min.Die-cut size	90*90mm	65*65mm	50*50mm	20*20mm
Max.Die-cut height	310mm	260mm	220mm	200mm
Die-cut pressure	11 T	8 T	5 T	3 T
Working speed	7 Times/min	8 Times/min	10 Times/min	12 Time/min
Motor voltage power	7.5HP 5.6KW	7.5HP 5.6KW	5HP 3.75KW	3HP 2.25KW
Overall dimension(mm)	2600*1250*1900	2450*1000*1800	2200*850*1650	1350*750*1500
Weight of whole machine	1900kg	1600kg	1200kg	700kg





Product show:















Old  blade adapter of YMQ115









New  blade adapter of YMQ115









Whole set machine









How the goods are packed?

Standard export wooden box, also can be packaged as customer's requirement.





Which transports you can receive the goods quickly?



The goods can be reached to your hand fast through below means of transport .So that you could use them and resale in time.







What service can we offer?



We will offer the most professional suggestion to help you start and expand your business!

We assure you of our best service at all times.



FAQ:



1. How many years have you exported the die cutting machine?

    We have exported for several years,we have mature and professional service system.



2. Why the customers choose you?

    We have high quality of die cutting machine and intimate service.



3. How is the price of die cutting machine?

    Our price is strong competitiveness, can save customer's cost.



4. What about your die cutting machine delivery time?

    According to customers order quantity to sure delivery time.





WELCOME TO CONTACT US WHENEVER YOU NEED US !
