Automatic Sliding/swing Door Safety Radar Sensor Motion 12~24V AC or DC MAX 4m Microwave and Microprocessor 50 60hz 10.525ghz
- Category: >>>
- Supplier: Bisen Smart Access Co. Ltd.
Share on (60639790863):
Product Overview
Description
Product Description
10.525GHz mircrorpocessor sensor for automatic gate operator door opener
Technology : Microwave and microprocessor
Transmitting frequency: 10.525GHz
Frequency density: 5mW/cm2
Radiation height: MAX 4m
Radiation angel: Horizontal: 120° vertical: 80°
Detection area standard data: 4m(width)*3m (depth)
Detection mode: Motion
Minimum detection speed: 5cm/s(test along the antennae coordinates)
Detection zone adjustment: Adjust the antenna angel.
Sensitivity adjustment: Adjust the potentiometer
Operating Temperature: -20℃~+55℃
Anti-Interference: EMC comply with the 89/336 EEC standard
Power supply frequenct: 50-60Hz
Power consumption: < 2W
Output: Standard relay output
Maximum contacts voltage: AC220V DC 28V
Maximum contact current: 1A
Output hold time: 1S
Technology : Microwave and microprocessor
Transmitting frequency: 10.525GHz
Frequency density: 5mW/cm2
Radiation height: MAX 4m
Radiation angel: Horizontal: 120° vertical: 80°
Detection area standard data: 4m(width)*3m (depth)
Detection mode: Motion
Minimum detection speed: 5cm/s(test along the antennae coordinates)
Detection zone adjustment: Adjust the antenna angel.
Sensitivity adjustment: Adjust the potentiometer
Operating Temperature: -20℃~+55℃
Anti-Interference: EMC comply with the 89/336 EEC standard
Power supply frequenct: 50-60Hz
Power consumption: < 2W
Output: Standard relay output
Maximum contacts voltage: AC220V DC 28V
Maximum contact current: 1A
Output hold time: 1S
Products Show
Company Profile
BISEN SMART ACCESS CO,.LTD was established in 1999, located in NanChang, China.
We are the biggest professional manufacturer for parking management system and equipments, gate and door automatic operators in China. more than 70 experienced engineers are engaging in R&D team , and more than 500 employees are working in manufacturer and service. We can provide quality ODM / OEM service for customers.
Our main products: Parking system auto-barrier gate, Sliding gate opener, Swing gate opener, Industrial sectional door opener, anti-terrorism road blocker, Hydraulic bollard, Pedestrian gate, Entrance control system etc.
Exhibition
Certifications
Manufacturing Technique
Testing Equipment
Our Services
1.OEM Manufacturing welcome: Product, Package.
2. MOQ: 1 piece
3. Warranty:1 year
4. We will reply you for your inquiry in 24 hours.
We have our own overseas service department and professional technology team, can meet different requirements of customers in the shortest time and supply the best service when you back home. To solve all the troubles back home and putting customer at first is our principle all the time!
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days, or it is 15-20 days if the quantity is very big. It is according to quantity.
Q: Do you provide samples ? Is it free or extra ?
A: We could offer the sample for charge, freight collect.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance, balance before shippment.
If you have another question, pls feel free to contact us as.
