TTA AGRICULTURE SPRAYING DRONE 15KG PAYLOAD







Intelligent Agriculture is the trend of all over the world. And the intelligent drone act as a important role in this world plan.
TTA Agriculture spraying drone can replace the traditional pesticide sprayer and it's speed is 40times of the traditional sprayer.


It will save 90% water and 30%-40% pesticide. Small droplet diameter make the pesticide more well-distribute and improve the effect.


At the same time, it will make the people faraway from the pesticide and reduce the pesticide remain of the crop.
Make the life more healthy, make the world more efficient.--TTA























































































SPECIFICATIONS FOR 15KG PAYLOAD AGRICULTURE SPRAYING DRONE








DIMENTION



Diagonal wheelbase


1630mm


Size Folded L*W*H


513*473*540mm


Container Material


Fiber glass


Container Volume


15kg













FLYING



Full payload flying time


15 min


Empty payload flying time


50 min


Flying Speed


0-15m/s


Flight Radius


1.5 km


Flying Height


0-200m


Landing approach


Vertical take-off and landing


Anti-wind


<8.0m/s (28.8km/h)











SPRAYING



Spray droplet diameter


60-180μm


Quantity of Nozzles


6 pcs


Spray Speed


0-15m/s


Spray Width


4-5.5M


Spray Height


1-3M above crop


Work Efficiency


2.5-4Acre/15min




Main Features





1.Six levels of wind resistance,rain proof,dust proof.
2.6 points positioning, stable taking-off.
3.Suitable for many kinds of application environment,-25-50degree
4.Using micro water extraction pump,output flow is stability.
5.Spraying width is Large area, so atomization is more equal.
6.All our drone can be folded, the transport is very convenient.
7.Quick release structure, easy to maintain .
8.Support airline design, semi-automatic flying.
9.Support breakpoint memory .
10.Carbon fiber and aviation aluminum,light and tough.
11.Excellent black box function,automatically record the flight data.









Detailed Images





































Machine Parts




Name: Quick release arm joint


Brand: TTA (patent obtained)


Material: Aviation aluminum


The whole machine is foldable with the quick release structure . Independent researched by TTA. Easy to transport , tough and durable, easy to maintain.











Main Features





Name: Brushless motor
Brand: TTA (customized)
Size: 8017
Rain-proof, dust -proof, durable and easy to maintain.






Machine Parts




Name: GCS
Platform:APP/PC





Support automatic route planning, can real-time monitor the copter data: flying height, distance, battery voltage, attitude angle and so on.









Main Features





Automatic route planning




The drone  will automatically flying and sprayig as the


designed route. Also can switch to manual hand from


the route planning easily.








Q&A





Independently design and manufacture. TTA concentrate on every spare part detaily.


Professional processes: design, testing, manufacture ,finished product testing ,package, delivery.







Q&C




There is a responsible person for each drone.


TTA will test every drone before delivery.


There is serial no. for every drone which can be used to check it's whole production process.





Packaging





Size: 70 (L) * 79 (W) * 95 (H)


Weight: 25kg


Packing list:


1.Fuselage include arms, motors, propellers, electronic speed controllers

2.Data link

3.Futaba remote controller (8FG)

4.Spraying equipment includes Micro pump / pesticide tank / nozzles

5.Assemble tools



The normal package is aviation industrial carrying case. Which will protect the drone very well. And we have designed special foam according to the drone structure. The drone inside the box will be fixed and box has wheels which make the transport easy an safe.
