Blast Freezer Manufacturers
- Category: >>>
- Supplier: Shengzhou Lanco Refrigeration Equipment Co. Ltd.
Share on (60641840451):
Product Overview
Description
Product Description
Feature:
1. The housing is in plastic-sprayed coat or rolled from aluminum plate,best corrosion protection, beautiful in shape.
2. Original coil arrangement to reduce the side resistance. The aluminum fins are fasten ed to the steel tubes by hydraulic expanding way, which is effective to reduce thermal contact resistance and improve thermal transfer.
3. After pressure test, wash with trichloroethylene to clean the oily dirt,moisture, oxide and other impurities inside. As such, no blocking trouble after filling with refrigerant in use.
4.Special fan motor, which is low in power consumption, large in air volume, low in noise, send far in air throw, guarantees good performance in humidity and low temperature.
5.Equipped with U-shaped electro-thermal tube that's good in insulation inside the coil,rational gap arrangement and power capacity to achieve desirable defrosting performance.
6.Groove-type channel clip, easy to install.
7.Filled with nitrogen before leaving factory.
| Ceiling Type Fast Frozen Unit Coolers Fan:Φ630mm Fin Space:9.0mm/18mm Inner-charge | |||||||||||||||||
| Model | SC4 Capacity (KW) | SC5 Capacity (KW) | Tube length | Surface | Circuit Vol. | Fan | Heater | InTube (inch) | OutTube (inch) | Net Weight (KG) | |||||||
| Airinlet Ta-25℃ Evaporation Te -31℃ | Airinlet Ta -34℃ Evaporation Te-40℃ | ||||||||||||||||
| R22 | R404A | R22 | R404A | m | m2 | dm3 | Fan Mot no. | Air Flow (m3/h) | Air Throw (m) | Fan Mot Amper (A) | Fan Mot Power (W) | Electric Defrost (A) | Electric Defrost (W) | ||||
| LK6T632 | 18.0 | 17.6 | 14.8 | 14.7 | 288 | 76 | 39.0 | 630*2 | 26600 | 31 | 6.4 | 3200 | 18.9Δ | 10800 | 7/8 | 1-5/8 | 280 |
| LK8T632 | 21.7 | 21.4 | 17.9 | 17.9 | 384 | 102 | 53.0 | 630*2 | 24200 | 29 | 6.4 | 3200 | 28.4Δ | 16200 | 1-1/8 | 2-1/8 | 310 |
| LK6T633 | 27.5 | 27.2 | 22.5 | 22.5 | 432 | 114 | 59.0 | 630*3 | 29900 | 32 | 9.6 | 4800 | 28.4Δ | 16200 | 1-1/8 | 2-1/8 | 380 |
| LK8T633 | 32.7 | 32.5 | 27.1 | 27.1 | 576 | 153 | 79.0 | 630*3 | 36300 | 30 | 9.6 | 4800 | 42.6Δ | 24300 | 1-3/8 | 2-1/8 | 420 |
| LK8T634 | 37.9 | 37.5 | 30.6 | 30.6 | 691 | 183 | 95.0 | 630*4 | 44800 | 31 | 12.8 | 6400 | 51.3Δ | 29250 | 1-3/8 | 2-1/8 | 510 |
| Defrost electric heating pipe connection:Δ triangle connection . | |||||||||||||||||
| Floor Type Fast Frozen Unit Coolers Fan:Φ630mm Fin Space:9.0mm/18mm Inner-charge | |||||||||||||||||
| Model | SC4 Capacity (KW) | SC5 Capacity (KW) | Tube length | Surface | Circuit Vol. | Fan | Heater | InTube (inch) | OutTube (inch) | Net Weight (KG) | |||||||
| Airinlet Ta-25℃ Evaporation Te -31℃ | Airinlet Ta -34℃ Evaporation Te-40℃ | ||||||||||||||||
| R22 | R404A | R22 | R404A | m | m2 | dm3 | Fan Mot no. | Air Flow (m3/h) | Air Throw (m) | Fan Mot Amper (A) | Fan Mot Power (W) | Electric Defrost (A) | Electric Defrost (W) | ||||
| LKY6T634 | 36.0 | 35.2 | 29.6 | 29.4 | 576 | 152 | 79.0 | 630*4 | 53200 | 31 | 12.8 | 6400 | 37.9Δ | 21600 | 2*7/8 | 2*1-5/8 | 560 |
| LKY8T634 | 43.4 | 42.8 | 36.4 | 35.8 | 768 | 204 | 105.0 | 630*4 | 48400 | 29 | 12.8 | 6400 | 56.8Δ | 32400 | 2*1-1/8 | 2*2-1/8 | 620 |
| LKY6T636 | 55.0 | 54.4 | 45.6 | 45.0 | 864 | 228 | 118.0 | 630*6 | 79800 | 32 | 19.2 | 9600 | 56.8Δ | 32400 | 2*1-1/8 | 2*2-1/8 | 760 |
| LKY8T636 | 65.4 | 65.0 | 55.4 | 54.2 | 1152 | 306 | 158.0 | 630*6 | 72600 | 30 | 19.2 | 9600 | 85.3Δ | 48600 | 2*1-3/8 | 2*2-1/8 | 840 |
| Defrost electric heating pipe connection:Δ triangle connection /star connection Y,Y must be connected to the neutralline. | |||||||||||||||||
