JT 1070 (2 2) Jig machine (Gravity separation) shaking table(concentrate separation) for gold ore

Product Overview

Description

JT-1070 (2-2) Jig Machine (Gravity Separation) + Shaking Table (Concentrate Separation) For Gold Ore

JT1070 (2-2) Saw-tooth Wave Jig Machine

Mineral Ore Separator for Final Size 0-5mm



Brand: HD HRF

JT SERIOUS SAWTOOTH WAVE JIG

Condition:  NEW 100%

GOLD ORE GRAVITY SEPARATION JIG MACHINE



1) The mineral jig machine is mainly used to separate nugget gold, diamond and other precious stones. If your gold is tiny, we recommend the instigating sluice box and centrifugal concentrator.

2) JT series jigger are the new type of energy saving and high efficient gravity separation equipment and developed based on the traditional Sine Wave Jig.

3) The difference between saw-tooth wave ladder jig and sine wave jig is that the pulsation curve for jigging is saw-tooth wave shape with speedy upward flow and slow downward flow.

4) Bed layer is elevated integrally and slowly dropped with a long effective loose time, allowing significant increase of handling capacity for unit screen surface, decrease of lower limit of grain size recovery and large save of make-up water for undersized fraction.

5) Industrial tests carried our of saw-tooth wave ladder jig and sine wave jig for comparison showed that the recovery rate for operation of Saw-tooth Wave Ladder Jig is raised by Sn:3.01%, W:5.5%, Pb:1.63%, Zn:2.04%.

6) The water consumption reduces 30%-40% with water consumption being decreased by 30-40%.

7) The area reduces 1/3 and the stroke also may adjusted.



JT-1070 jig machines in stock for prompt delivery for clients



Product Principle

1) Saw-tooth wave jig is revised and manufactured, based on the stratified theory and the adequate analysis of other conventional jigs.

2) The jigging pulsation curve----produced by saw-tooth wave jig----is in the shape of saw-tooth wave which makes upward water flow quicker than downward water flow.

3) The feature that upward time is shorter than downward time solves the problem that time and action of upward/downward water flows.

4) This breakthrough dramatically amplifies the loose degree and mitigates suction action, which facilitates precipitation of coarse ores and improves ore recovery rate.



Features and Benefits

* Ore dressing of our saw-tooth wave ladder jig is capable of handling almost full sizes of mineral materials other than very fine material.

* It’s with a simple process operation, heavy duty equipment handling capacity with final products being obtained through one time separation.

* Jigger can achieve a good result in processing such as placer gold, tantalum-niobium, titanium,tungsten,iron, tin, hematite, cope,manganese, barite, zirconium and chrome etc.



Main Technical Parameter





MINE MESH DECK FOR FINAL PRODUCT SIZE 0~5MM



JIGGING LINE DESIGN NEW 100%



FACTORY DELIVERY WITH RUBBER CONVEYORS



JT-1070 TWO SETS SHIPPED TO USA



Questions From Engineers

 1) What is the raw ore material ?

 2) What is the input size of raw material ?

 3) What is the dealing capacity per hour that needed ?

 4) What is the output size of final product ?



REAL WORKING SITES FROM OUR

Mine Jigging Line Complete Machines



After jig machines, to ball mills for fine grinding





Final selection for finished fine pure ore
