1) Switch between cooling and heating mode via menu.
2) One channel of temperature sensor is used to adjust showcase temperature.
3) With temperature sensor self-test function, protection and alarm functions are available in case fault is detected.
Product Description
Technical parameters
Temperature measuring range :
-50℃~99℃
Resolution:
0.1℃
Accuracy:
±1℃(-50℃~70℃)
Sensor error delay :
1minute
Power supply :
220VAC±10%, 50/60Hz
Power consumption:
<3W
Sensor :
NTC sensor (1PC)
Relay contact capacity:
Cool (10A/250VAC); Heat (10A/250VAC)
Ambient temperature:
0℃~60℃
Storage temperature:
-30℃~75℃
Relative humidity:
20~85%(No condensate)
Specification and size
Front panel size:
75(L)*34.5(W)(mm)
Mounting size:
71(L)*29(W)(mm)
Product size :
75(L)*34.5(W)*85(D)(mm)
Senor length :
2m(include the probe)
Shipping terms: 1)STC-1000 Sample time:3-5days(without LOGO printing),5-7days(with LOGO printing) 2)STC-1000 Production time:15-25days(Depends on the Qty) after advanced payment received
QC: All digital thermometer must have been inspected 5 times before delivery 1) Checking the raw material after they arrived our factory 2) Checking all the details while the production line operated 3) Checking the goods after they are finished 4) Checking all the goods after they are packed
6
We can create a custom product specifically for you.
Application
Other Producst
1) Refrigeration, deforting, humidity and humidity&temperature controllers, more details click #
3) Gas leak detector and Electric cabient, more details click #
Products testing
Each STC-1000 would be strictly tested before delivery
Certificate
Certificate & Testing:CE,ROHS, ISO2000:901
Packaging & Shipping
Each product has a small packaging,The packing box can also be produced as customer requirements. Carton is export standard carton.
Company Information
For over 15 years, XUZHOU SANGE AUTOMATIC CONTROL EQUIPMENT CO.,LTD has specialized in designing and manufacturing temperature controllers, temperature control systems, and temperature sensors. We sell a standard line of products as well as provide custom design services. All of our products are developed and designed at our state-of-the-art manufacturing facility inXuzou, Jiangsu, China.
